Switch with
switch lever
T i p :
Make sure that the switch lever or
slider is always pushed up against
the end stop.

Quarter pipe

The switch with switch lever are used to determine the direction
of the course.
The separate PLUS XS Motor Set can be used to extend and
power the switch. The assembly instructions provide information
on how to install this set in obstacle course 1.
The balls roll from the flex-rail onto the quarter pipe, which con-
sists of three construction plates. It is inclined slightly upward
and to the side so that the balls drop into the rotary funnel after
changing direction.
