Stopping point

T i p :
Make sure that the flex-rail profile or
slider is always pushed up against
the end stop.
T i p :
Make sure that building block 5
with connector 30 is connected
flush at the top with the 15x30x5
construction plate with three slots.
This will ensure that the stopping
point functions correctly.
Switch with
switch lever
T i p :
Make sure that the switch lever or
slider is always pushed up against
the end stop.
30
30
5
5
11
The balls can be stopped at the stopping point and then
released.
The switch with switch lever are used to determine the direction
of the course.
