Obstacle course 2

Rotary funnel

T i p :
Ensure that all components for
the rotary funnel mount as well as
the subsequent flex-rail are aligned
correctly, so that the ball falls through
the hole directly onto the next
flex-rail.
Obstacle course 3

Automatic cross-over

Ensure that all components in the
automatic cross-over are installed
and aligned correctly and that the
cross-over moves easily. Otherwise it
may not operate correctly.
■ This model particularly suited for those who are new to using the ball
obstacle course.
The balls are transported up by the elevator and after passing through the
cross-over roll down two different routes to the rotary funnel. Here the
balls collect and roll back on a flex-rail to the ball magazine.
■ This action-packed obstacle course includes many dynamic obstacles as well as a switch and a
stopping point. Here are a few tips about the individual obstacles to ensure they work correctly.
T i p :
In the rotary funnel the balls
from both routes again
merge on the subsequent
flex-rail.
After the ball has been knocked
off the magnetic ball holder,
it rolls into the automatic
cross-over, which routes the
balls alternately to the left
and right.
