Obstacle course 1

Automatic cross-over

Ensure that all components in the
automatic cross-over are installed
and aligned correctly and that the
cross-over moves easily. Otherwise it
may not operate correctly.

Switch

Make sure that the flex-rail profile or
slider is always pushed up against
the end stop.
■ This action-packed obstacle course includes many dynamic obstacles as well as two switches and a
stopping point. Below are a few tips on how to ensure that the individual obstacles work correctly.
T i p :
T i p :
After the ball has been knocked off the
magnetic ball holder it rolls
into the automatic cross-over
which routes all incoming balls
alternately to the left and right.
The mechanical switch can
be used to adjust the route
of the flex-rails.
The separate PLUS XS Motor Set can be used to
extend and power the switch. The assembly instructions pro-
vide information on how to install this set in obstacle course 1.
