Installation and Configuration
Name
COREVDD
PLLVDD
IOVDD\
3.3V
LED+
12
Table 3-7: S5U13L01P00C100 Power Mapping
Purpose
S1D13L01 COREVDD 1.5V Fixed
S1D13L01 PLLVDD 1.5V Fixed
S1D13L01 IOVDD 1.8/3.3V Typical
SG-210 VDD 3.3V Fixed
Backlight for panel, 38V/60mA max
Figure 3-2: Voltage Adjustment Locations (Red)
Seiko Epson Corporation
Adj.
Range
—
1.5V
VR1
1.5~3.8V
—
3.3V
JP503
12~38V
S5U13L01P00C100 Evaluation Board
Rev. 1.3
