2.2. Jumper/Connector Listing

Jumper/Connector Description
AGP1 AGP slot
BAT1 Battery
CN1 Line Out, Line In, Mic In ports
COM1 COM1 connector
COM2 COM2 connector (K7NCR18D series)
DIMM1-3 Memory module connectors
FAN1/FAN2/FAN3 CPU fan connector/ Chipset fan connector/
System fan connector
FLP1 Floppy disk connector
FP1/FP2 Case Signal Connector: PWRBTN, RESET, KEY LOCK,
SPEAKER, HDD_LED, POWER_LED, ACPILED
IDE1/IDE2 Hard disk connectors (Primary IDE/Secondary IDE)
IR1 IR connector
CIR1 CIR connector
J2 Smart Card connector
J4/J5 Wake on modem/ Wake on LAN
J10/J11 CD input connector
J12 AUX input connector
J13 Clear CMOS data
J1 SPDIF connector
J6 ACR slot
JP6 Audio front panel header
KYB1 PS2 keyboard and mouse ports
PCI1-PCI4 PCI slots
PRN1 Print port connector
PWR1 ATX power connector
UL1 USB ports and 10/100 LAN connector
USB2 USB ports
USB1 USB module connector, providing 2 additional USB ports
VGA1 VGA connector (K7NCR18G series)
JP9/JP10 CPU frequency selection (JP9-Version A/ JP10-Version D)
JP2 Second VGA/TV-out module (with SPDIF output)
connector (K7NCR18G series)
JP11 Memory voltage selection
J16/J17 SATA1/SATA2 (K7NCR18D-Pro 2/18G-Pro 2)
J8 Case open alert
J3 SATA selection
