Power ON Function [BUTTON ONLY]
Allows you to choose a way to power on. The options include Password, Hot KEY,
Mouse Left, Mouse right, Any KEY, BUTTON-ONLY, and Keyboard 98.
KB Power ON Password [Enter]
This setting item allows you to set a password for keyboard powering on.
Hot Key Power ON [Ctrl-F1]
Allows you to choose one of the hot keys to power on from F1 to F12.
Onboard FDC Controller [Enabled]
This setting item allows you to enable or disable the onboard FDC controller.
Onboard Serial Port 1/Port 2
Select an address and corresponding interrupt for the 1st and 2nd serial ports. The
choices: 3F8/IRQ4, 2F8/IRQ3, 3E8/IRQ4, 2E8/IRQ3, Disabled, and Auto.
UART Mode Select
Select an infrared port mode. The options are: Normal, IrDA, ASKIR, and SCR.
RxD, TxD Active
The options are: Hi,Hi, Hi,Lo, Lo,Hi, and Lo,Lo.
IR Transmission Delay
The options are: Enabled and Disabled.
UR2 Duplex Mode
This item selects the IR function when the choice of the UART mode is ASKIR. The
options are: Full and Half.
Use IR Pins
The options are: RxD2,TxD2 and IR-Rx2Tx2
Onboard Parallel Port
This item allows you to determine access onboard parallel port controller with
which I/O address. The options are: 378/IRQ7, 278/IRQ5, 3BC/IRQ7, and
Disabled.
Parallel Port Mode
Select an operating mode for the onboard parallel port. Normal EPP (Extended
Parallel Port) ECP (Extended Capabilities Port) ECP+EPP PC AT parallel port
Bi-directional port Fast, buffered port Fast, buffered, bi-directional port.
Set to Normal unless you are certain your hardware and software both support
EPP or ECP mode. The options are: SPP, EPP, ECP, and ECP+EPP.
EPP Mode Select
The options are: EPP 1.7 and EPP 1.9
