SPDIF Device (Only K7NCR18D/18D-Pro/18D-Pro 2)
Each of these connectors is for connecting an optional SPDIF device as below:
NOTE: As to the signal
must plug in pin header J1 position "1" on the mainboard. Be
careful not plugging in wrong position.
WinFast K7NCTS
K7NCR18G series can support second VGA/TV-out module (with SPDIF output)
connector.
NOTE : To determine to output video through VGA port or TV-OUT port,
enter BIOS Setup and set the K7NCTS Card Support of Advanced
Chipset Features to either TV OUT or CRTB OUT.
in the housing as below, please make sure
13
