PowerFlex 6000 Drive (P_PF6000)
Table 2 - Visualization Files: Images (.png)
FactoryTalk View SE Software
All .png files in the images folder
Table 3 - Visualization Files: Global Objects (.ggfx)
FactoryTalk View SE Software
(RA-BAS) Common Faceplate Objects
(RA-BAS) P_VSD Graphics Library
(RA-BAS) Process Alarm Objects
(RA-BAS) Process Diagnostic Objects
(RA-BAS) Process Faceplate Motor Objects
(RA-BAS) Process Help Objects
(RA-BAS) Process Interlock Objects
(RA-BAS) Process Mode Objects
Table 4 - Visualization Files: Standard Displays (.gfx)
FactoryTalk View SE Software
(RA-BAS) Common-AnalogEdit
(RA-BAS) P_Alarm-Faceplate
(RA-BAS) P_Alarm-Help
(RA-BAS) P_Mode-Config
(RA-BAS) P_Mode-Help
(RA-BAS) P_PF6000-Faceplate
(RA-BAS) P_PF6000-Quick
(RA-BAS) Process Motor Family-Help
10
When PNG files are imported, they are renamed by FactoryTalk View software
with a .bmp file extension, but retain a .png format.
FactoryTalk View ME Software
All .png files in the images folder
The Global Object files (.ggfx file type) in the following table are Process Library
display elements that are created once and referenced multiple times on multiple
displays in an application. When changes are made to a Global Object, all
instances in the application are automatically updated.
FactoryTalk View ME Software
(RA-BAS-ME) Common Faceplate Objects
(RA-BAS-ME) P_VSD Graphics Library
(RA-BAS-ME) Process Alarm Objects
(RA-BAS-ME) Process Diagnostic Objects
(RA-BAS-ME) Process Faceplate Motor Objects
(RA-BAS-ME) Process Help Objects
(RA-BAS-ME) Process Interlock Objects
(RA-BAS-ME) Process Mode Objects
The Standard Display files (.gfx file type) in the following table are the Process
Library displays that you see at runtime.
FactoryTalk View ME Software
N/A
(RA-BAS-ME) P_Alarm-Faceplate
(RA-BAS-ME) P_Alarm-Help
(RA-BAS-ME) P_Mode-Config
(RA-BAS-ME) P_Mode-Help
(RA-BAS-ME) P_PF6000-Faceplate
(RA-BAS-ME) P_PF6000-Quick
(RA-BAS-ME) Process Motor Family-Help
Rockwell Automation Publication SYSLIB-RM057A-EN-P - January 2017
Description
These are the common icons that are used in the global
objects and standard displays for all Process Objects.
Description
Global objects used on process object faceplates.
Drive global object device symbols used to build
process graphics.
Global objects used for managing alarms on process
object faceplates.
Diagnostic global objects used on process
object faceplates.
Motor global objects used on process object faceplates.
Global objects used for all process objects help displays.
Global objects used for managing interlocks and
permissives on process object faceplates.
Global objects used for managing modes on process
object faceplates.
Description
Faceplate used for analog input data entry. The FactoryTalk
View ME faceplates use the native analog input data entry
so no file is required.
The faceplate that is used for the object
Alarm Help information that is accessed from the
P_AIarm faceplate.
The Configuration Display used to configure the
P_Mode object.
Mode Help information that is accessed from the
Help faceplate.
The faceplate display that is used for the object
The Quick display that is used for the object
The Help display for Motor objects
