Table 4 - Visualization Files: Standard Displays (.gfx)
FactoryTalk View SE Software
(RA-BAS) P_Intlk-Faceplate
(RA-BAS) P_Perm-Faceplate
(RA-BAS) P_ResInh-Faceplate
(RA-BAS) P_RunTime-Faceplate
(RA-BAS) Process Interlock Family-Help
Table 5 - Visualization Files: HMI Tags (.csv)
FactoryTalk View SE Software
N/A
FactoryTalk View ME Software
(RA-BAS-ME) P_Intlk-Faceplate
(RA-BAS-ME) P_Perm-Faceplate
(RA-BAS-ME) P_ResInh-Faceplate
(RA-BAS-ME) P_RunTime-Faceplate
(RA-BAS-ME) Process Interlock Family-Help
HMI Tags are created in a FactoryTalk View ME application to support tab
switching on Process Library faceplates. The HMI tags can be imported via the
comma-separated values file (.csv file type) in the following table.
FactoryTalk View ME Software
FTVME_PlantPAxLib_Tags_3_5_xx.csv
where xx = the service release number.
Rockwell Automation Publication SYSLIB-RM057A-EN-P - January 2017
PowerFlex 6000 Drive (P_PF6000)
Description
Optional
The interlock faceplate used for the object.
Use this file if your Discrete Output has an associated
P_Intlk object and you enable navigation to its faceplate
from the Discrete Output faceplate.
Optional
Permissive faceplate that is used for the object
Use this file if your object has an associated P_Perm object
and you enable navigation to the P_Perm faceplate from
the object faceplate.
Optional
Restart/inhibit faceplate display that is used for the object
Use this file if your object has an associated P_ResInh
object and you enable navigation to the P_ResInh
faceplate from the object faceplate.
Optional
RunTime faceplate display that is used for the object
Use this file if your object has an associated P_RunTime
object and you enable navigation to the P_RunTime
faceplate from the object faceplate.
Optional
Interlock/permissives help display that is used for
the object
Use this file if you use the P_Intlk or P_Perm faceplate.
Description
These tags must be imported into the
FactoryTalk View ME project to support switching tabs on
any Process Object faceplate.
