4. Controls, Alarms and Indicators

Power Switch Mute Control Alarm High Pressure Low Pressure
& Alarm Reset & Indicator Indicator Indicator Indicator
mmHg
-
+
N
R
Hi
mmHg
mmHg
Lo
On/Reset Alarm Wait Service Comfort
Indicator Indicator Indicator Control
Static Control Power Fail Pump Fault
& Indicator Indicator Indicator
Pump Controls The pump front panel has the following controls:
Switches the mains power to the pump on and off.
POWER Switch (and
RESET ALARM)
The green indicator is illuminated when the mains
power is connected and the pump switched on.
The switch is also used to reset the pump after an alarm
condition has been detected.
Selects the operating mode, either or .
STATIC Mode Static Dynamic
mode is confirmed when the yellow indicator on
Static
the button is illuminated.
When mode (default) is selected the yellow
Dynamic
indicator will be extinguished.
An audible alarm mute is provided to cancel warning
Alarm MUTE
sounds during an alarm condition.
This is a rotary action control to set the relative firmness/
COMFORT CONTROL
softness of the mattress for patient comfort.
mmHg
+
11
