DEMO MANUAL DC2069A

parts List

ITEM QTY
Required Circuit Components
1 1
2 2
3 2
4 5
5 3
6 4
7 1
8 2
9 1
10 2
11 1
12 1
13 1
14 2
15 2
16 1
17 2
18 1
19 2
20 2
21 1
22 1
23 1
24 2
25 1
26 1
27 5
28 1
29 1
30 1
31 1
32 1
33 1
34 1
35 1
36 1
37 1
38 1
39 1
40 1
41 1
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE

PART DESCRIPTION

C12 CAP., X7R, 1nF, 16V, 20%, 0603
C13, C47 CAP., X5R, 0.22uF, 16V, 10%, 0603
C14, C15 CAP., X7R, 3.3nF, 16V, 20%, 0603
C41, C42, C43, C44, C46 CAP., X7R, 2.2µF, 100V 10%, 1210
C45, C79, C58 EP-cap, 33µF, 63V, 20%
C48, C49, C50, C51 CAP., X7R, 10µF, 35V 10%, 1210
C55 EP-CAP, 150µF, 25V, 20%
C56, C57 CAP., X5R, 2.2µF, 10V, 10%, 0603
C59 CAP., X7R, 0.1µF, 16V, 10%, 0603
C60, C61 CAP., X7R,4.7nF, 16V, 10%, 0603
C62 CAP., NP0, 220p, 16V, 5%, 0603
C63 CAP, X7R, 6.8nF, 50V, 10%, 0603
C65 CAP., X7R, 1µF, 100V, 10%, 1210
C66, C73 CAP., X7R, 1.0µF, 16V, 10%, 0603
C67, C68 CAP., X7R, 0.068µF, 16V, 10%, 0603
C69 CAP., X5R, 4.7µF, 6.3V, 10%, 0603
C83, C84 CAP., X7R, 0.47uF, 16V, 10%, 0603
C85 CAP., C0G, 1000pF, 100V, 10%, 1206
C87, C90 CAP., X7R, 0.01µF, 100V, 10%, 0603
D1, D2 ULTRA FAST RECTIFIER SINGLE, SOD-123F
L1 IND, 4.7µH
M1 MOSFET, N-CHANNEL, 60V PG-TDSON-8
M2 MOSFET, N-CHANNEL, 60V PG-TDSON-8
M3, M4 MOSFET, N-CHANNEL, 25V PG-TDSON-8
R2 RES., CHIP, 196k, 0.1W, 1%, 0603
R3 RES., CHIP, 8.06k, 0.1W, 1%, 0603
R5, R8, R9, R23, R24 RES., CHIP, 10Ω, 0.1W, 1%, 0603
R11 RES., CHIP, 110k, 0.1W, 1%, 0603
R13 RES., CHIP, 113k, 0.1W, 1%, 0603
R14 RES., CHIP, 35.7k, 0.1W, 1%, 0603
R15 RES., CHIP, 1.2, 0.25W, 1%, 1206
R16 RES., CHIP, 10k, 0.1W, 1%, 0603
R44 RES., SENSE, 0.004Ω, 2W, 1%, 2512
R47 RES., CHIP, 215k, 0.1W, 1%, 0603
R48 RES., CHIP, 21.0k, 0.1W, 1%, 0603
R49 RES., CHIP, 124k, 0.1W, 1%, 0603
R50 RES., CHIP, 4.99k, 0.1W, 1%, 0603
R54 RES., CHIP, 3.48k, 0.1W, 1%, 0603
R55 RES., CHIP, 5.90k, 0.1W, 1%, 0603
R56 Res., SENSE, 0.005Ω, 1W, 1%, 2512
R57 RES., CHIP, 0.003, 2W, 1%, 2512
MANUFACTURER/PART NUMBER
AVX, 0603YC102MAT4A
AVX, 0603YD224KAT2A
AVX, 0603YC332MAT4A
AVX, 12101C225KAT2A
SUNCON, 63HVH33M
MURATA, GRM32ER7YA106KA12L
SANYO, 25HVH150M
AVX, 0603ZD225KAT2A
AVX, 0603YC104KAT2A
AVX, 0603YC472KAT2A
AVX, 0603YA221JAT2A
AVX, 06035C682KAT2A
AVX, 12101C105KAT2A
AVX, 0603YC105KAT2A
AVX, 0603YC683KAT2A
AVX, 06036D475KAT2A
MURATA, GRM188R71C474KA88D
AVX, 12061A102KAT2A
MURATA, GRM188R72A103KA01D
CENTRAL SEMI., CMMR1U-02 TR
COILCRAFT, SER2915L-472KL
INFINEON, BSC028N06NS
INFINEON, BSC016N06NS
INFINEON, BSC010NE2LSI
PANASONIC, ERJ-3EKF1963V
VISHAY, CRCW06038k06FKEA
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW0603110KFKEA
VISHAY, CRCW0603113KFKEA
PANASONIC, ERJ-3EKF3572V
VISHAY, CRCW12061R20FKEA
VISHAY, CRCW060310K0FKEA
SUSUMU, RL3264SW4-004M-F-T5
VISHAY, CRCW0603215KFKEA
PANASONIC, ERJ-3EKF2102V
PANASONIC, ERJ-3EKF1243V
PANASONIC, ERJ-3EKF4991V
VISHAY, CRCW06033K48FKEA
VISHAY, CRCW06035K90FKEA
PANASONIC, ERJM1WTF5M0U
PANASONIC, ERJM1WTF3M0U
dc2069afb
