DEMO MANUAL DC2069A
parts List
ITEM QTY
81 3
82 3
83 1
84 2
85 1
86 1
87 1
88 2
89 2
90 1
91 1
92 1
93 1
94 1
95 1
96 1
97 1
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
R96, R97, R99 RES., CHIP, 4.99k, 0.1W, 1%, 0603
R51, R58, R86 RES., CHIP, 1Ω, 0.1W, 1%, 0603
R52 RES., CHIP, 1k, 0.1W, 1%, 0603
R53, R85 RES., CHIP, 100k, 0.1W, 1%, 0603
R61 RES., CHIP, 33.2k, 0.1W, 1%, 0603
R68 RES., CHIP, 102k, 0.1W, 1%, 0603
R73 RES., CHIP, 11.3k, 0.1W, 1%, 0603
R75, R77 RES., CHIP, 549Ω, 0.1W, 1%, 0603
R83 RES., CHIP, 27.4k, 0.1W, 1%, 0603
R89 RES., CHIP, 19.1k, 0.1W, 1%, 0603
R90 RES., CHIP, 80.6k, 0.1W, 1%, 0603
R91 RES., CHIP, 41.2k, 0.1W, 1%, 0603
R92 RES., CHIP, 59.0k, 0.1W, 1%, 0603
R93 RES., CHIP, 11.5k, 0.1W, 1%, 0603
SW1 SWITCH, TACTILE SPST-NO 0.05A 12V
U2 IC., IDEAL DIODE CONTROLLER, DFN-6L
U3 IC., OP AMP, SO8
MANUFACTURER/PART NUMBER
PANASONIC, ERJ-3EKF4991V
VISHAY, CRCW06031R00FKEA
PANASONIC, ERJ-3EKF1001V
PANASONIC, ERJ-3EKF1003V
VISHAY, CRCW060333K2FKEA
VISHAY, CRCW0603102KFKEA
VISHAY, CRCW060311K3FKEA
VISHAY, CRCW0603549RFKEA
VISHAY, CRCW060327K4FKEA
PANASONIC, ERJ-3EKF1912V
PANASONIC, ERJ-3EKF8062V
PANASONIC, ERJ-3EKF4122V
VISHAY, CRCW060359K0FKEA
VISHAY, CRCW060311K5FKEA
WÜRTH, 434 123 050 816
LINEAR TECH., LTC4359CDCB#TRPBF
LINEAR TECH., LT1636CS8#PBF
