Linear Technology DC2069A Demo Manual page 5

parts List
ITEM QTY
42 1
43 1
44 1
45 1
46 2
47 1
48 1
49 1
Optional Components
50 1
51 1
52 1
53 1
54 1
55 1
56 1
57 1
58 3
59 1
60 1
61 3
62 2
63 3
64 3
65 3
66 6
67 1
68 1
69 1
70 0
71 3
72 1
73 1
74 1
75 1
76 2
77 2
78 1
79 6
80 1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE PART DESCRIPTION
R62 RES., CHIP, 3.3Ω, 0.1W, 5%, 0603
R63 RES., CHIP, 1.10k, 0.1W, 1%, 0603
R64 RES., CHIP, 3.01k, 0.1W, 1%, 0603
R65 RES., CHIP, 30.1k, 0.1W, 1%, 0603
R67, R71 RES., CHIP, 53.6k, 0.1W, 1%, 0603
U1 IC., BATTERY CHARGE CONTROLLER, 64-QFN
FAB, PRINTED CIRCUIT BOARDS
STENCIL (TOP AND BOTTOM IMAGES)
C74 CAP., X7R, 0.1µF, 16V, 10%, 0603
C76 CAP., X7R, 2.2uF, 100V, 10%, 1206
C77 CAP., X7R, 0.01µF, 16V, 10%, 0603
D10 LED, GREEN, 0603
D12 LED, RED, 0603
D14 DIODE, TVS UNI-DIR 70V 400W SMA
D15 DIODE, TVS UNI-DIR 24V 400W SMA
D16 DIODE, ZENER 12V 150MW SOD523
D19, D20, D21 DIODE, BAV99 SOT23
F1 FUSE
F1 FUSE HOLDER
JP1, JP3, JP4 4 PIN 0.100 SINGLE ROW HEADER
XJP1, XJP4 SHUNT, 0.1" CENTER
J1, J2, J3 HOUSING, +PIN, RED
J1, J2, J3 HOUSING, –PIN, BLACK
J1, J2, J3 STAPLES FOR PCB ASSY.
J1, J2, J3 RIGHT ANGLE PCB CONTACTS
J4 MODULAR JACK
L2 IND, 0Ω 0603
M5 MOSFET, N-CHANNEL, 100V POWER 56
M1-1, M2-1, M3-1, M4-1 MOSFET, N-CHANNEL
(OPT)
Q4, Q13, Q14 NPN TRANSISTOR, SOT23
Q6 P-CH MOSFET, 50V, SOT23
R26 RES., CHIP, 10Ω, 0.1W, 1%, 0603
R6 RES., CHIP, 3.32k, 0.1W, 1%, 0603
R12 RES., CHIP, 1.3k, 0.1W, 1%, 0603
R46, R94 RES., CHIP, 10k, 0.1W, 1%, 0603
R17, R19 RES., CHIP, 100Ω, 1W, 1%, 2512
R21 RES., CHIP, 10Ω, 1/8W, 1%, 0805
R22, R60, R66, R69, R100, RES., CHIP, 0Ω, 0.1W, 0603
R101
R84 RES., CHIP, 215k, 0.1W, 1%, 0603
DEMO MANUAL DC2069A
MANUFACTURER/PART NUMBER
PANASONIC, ERJ-3GEYJ3R3V
VISHAY, CRCW06031K10FKEA
PANASONIC, ERJ-3EKF3011V
VISHAY, CRCW060330K1FKEA
VISHAY, CRCW060353K6FKEA
LINEAR TECH., LT8490EUKJ#PBF
DEMO CIRCUIT 2069A
STENCIL DC2069A
AVX, 0603YC104KAT2A
AVX, 12061C225KAT2A
AVX, 0603YC103KAT2A
ROHM, SML-512PW (A)
ROHM, SML-512UW
DIODES INC., SMAT70A-13-F
DIODES INC., SMAJ24A-13-F
DIODES INC., DDZ9699T-7
DIODES INC., BAV99-7-F
LITTELFUSE, 142.6185.5306
LITTELFUSE, 178.4265.0002
SAMTEC, TSW-104-07-L-S
SAMTEC, SNT-100-BK-G
ANDERSON POWER, 1327
ANDERSON POWER, 1327G6
ANDERSON POWER, 114555P2
ANDERSON POWER, 1377G12
TE CONNECTIVITY, 5555165-1
VISHAY, CRCW06030000Z0ED
FAIRCHILD, FDMS86101
DIODES INC., MMBT3904-7-F
DIODES, BSS84-7-F
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW06033K32FKEA
VISHAY, CRCW06031K30FKEA
VISHAY, CRCW060310K0FKEA
PANASONIC, ERJ-1TNF1000U
PANASONIC, ERJ-6ENF10R0V
VISHAY, CRCW06030000Z0ED
VISHAY, CRCW0603215KFKEA
