Specifications
Form Factor
Case Form Factor
Case Dimensions
Case Weight
Manifold Weight
Case Weight in Package
Expansion Slots
Storage
Radiator Top
Radiator Front
Maximum GPU Length
Maximum GPU Height
Maximum PSU Length
Front Panel I/O
Ports
Pump Compatibility
Cables
Cable Lengths
Vertical GPU Mount
Lighting
Materials
Manufacturing Process
Assembly
Spectre | Assembly Manual
XL-ATX (Max: 320mm x 285mm 7 Expansion Slots, 8th slot fits but
component cannot be mounted), E-ATX, ATX, M-ATX, Mini-DTX,
Mini ITX.
Mid Tower
L 533 mm x W 303 mm x H 575 mm
16 Kg
8 Kg
18 Kg
x7
2.5" x3
360mm (Up to 60mm thick with 1 set of 25mm fans)
360mm (Up to 60mm thick with 1 set of 25mm fans)
500mm
150mm mounted on motherboard
(Unlimited height if vertically mounted)
280mm
No Front I/O. Vandal Switch Power Button 19mm
x6 G1/4" BSPP; x1 Fill; x1 Drain
Any D5 pump (Pump not included)
Integrated Cable Management is for 4mm sleeved cables
There is space for excess cable length inside of the PSU shroud.
For exact lengths see additional information:
https://bit.ly/Spectre-add-info
x1 included with ribbon cable
(2
Mount can be purchased separately for dual GPUs)
nd
Integrated 30cm LED Strip position under top panel
(Install during case assembly)
6061 Aluminium, Cast Acrylic, 304 Stainless Steel
CNC Router, CNC Mill, CNC Lathe
Assembled by hand
