Tools Required; Assembly Note - SINGULARITY COMPUTERS SPECTRE 2.0 Assembly Manual

Tools Required

• M3 Hex Key – Not included
• M4 Hex Key – Not included

Assembly Note

1. Spectre is built from thick billet alloy parts with very tight tolerances. There is no flex in the
metal parts like there is on other cases. The case is designed for all assembly to be done with
the screws still slightly loose so that everything can settle into position. Then once the
assembly is complete you can go back later and tighten the screws. (Be careful not to over
tighten). Any loss of anodizing or paint under the fasteners is a warning that you are going
too tight.
2. All fasteners on the manifold are carefully checked for tension during and after pressure
testing during assembly at the factory. They are tightened to an exact specification which
allows for the many thermal cycles the case will experience during its lifetime. This means
that it is possible for 1-3 of the manifold screws to come out during shipping from vibration.
If this happens to you replace them carefully and copy the tension from the surrounding
fasteners of the same type. This will not void your warranty.
Spectre | Assembly Manual
• M6 Metric Hex Key – Not included
