Industrial Electronic Devices
CHARACTERISTICS:
The HD67B78-A1 is a PROFINET Master / EtherNet/IP converter.
It allows the following characteristics:
Up to 496 bytes in reading and 496 bytes in writing;
Two-directional information between EtherNet/IP and PROFINET;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67B78 software on your PC in order to perform the following:
Define the parameter of the PROFINET;
Define the parameter of the EtherNet/IP;
Define the list of PROFINET slaves connected to the converter;
Update the device.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual PROFINET Master / EtherNet/IP
Document code: MN67B78_ENG
INFO:
www.adfweb.com
Revision 1.000
Page 6 of 28
