Quantum Scalar i40 and Scalar i80: Bezel Replacement
6-66553-03 Rev B
February 2014
Figure 1 Bezel Screw Locations
on Bottom of Library
Bottom
bezel
screws
4
5 Slide the library one to two inches forward out of the rack, or over the edge
of the table or desk, to access the two bottom bezel screws.
Caution: Do not tip the library or tilt it on its side.
6 Remove and set aside the two screws securing the bezel to the bottom of
the chassis (see Figure
7 Remove and set aside the two screws securing the bezel to the top of the
chassis (see Figure 2
1).
on page 5).
Removing the Bezel
