Quantum Scalar i40 and Scalar i80: Bezel Replacement
6-66553-03 Rev B
February 2014

Creating a Backup Map of Cartridge Locations

Removing the Bezel

2
Because you need to completely remove the magazines from the library, you
should create a backup "map" so you have the slot position of each cartridge.
The Library Configuration report, which shows the barcodes for each slot,
provides a convenient backup "map" if the cartridges get mixed-up or dropped.
1 From the Web client, select Reports > Library Configuration.
2 Click the Show Barcodes button.
The screen displays a map of the library showing the location of each
cartridge, by barcode.
3 Click the "print" icon in the upper right corner to print the report.
Alternatively, take a screen capture of the report and save or print it, or copy
the map by hand.
These instructions explain how to remove the bezel from the Scalar i40 and
Scalar i80 libraries:
1 Stop all library operations.
a Prepare host applications by following the vendor instructions for
stopping all commands to the library.
b Be sure all library operations have stopped.
2 Remove all magazines completely from the library; complete the following
steps for each magazine:
Note: When removing magazines from a library, label them so that you
can reinstall them in the same locations.
a On the Operator panel, select Actions > Magazine.
b Select a magazine and press Release.
c When prompted, remove the magazine completely.
Note: There is less chance of scratching or damaging the new bezel when
you install it if you completely remove the magazines. On the Scalar
i80, it is easier to perform this procedure with at least the bottom
two magazines completely removed. You need room to maneuver
your fingers on the sides of the bezel.
