6

Overview of sources

The output values of the winder function blocks can be obtained from the following sources:
-1
Frequency [s ]
Output frequency of controller
Q.8900 –
Output frequency of gear stage
Q.8900 –
Boolean values
PID controller: control deviation < P.812
Q.8920 –
Coil Size Limit Reached
Q.8925 –
Coil Size Limit Reached
Q.2926 –
Percentages [%]
Current control difference
Q.8940 –
Speed Factor at Dact
Q.8941 –
Speed Factor at Dact
Q.8942 –
Torque Factor at Dact
Q.8943 –
Torque Factor at Dact
Q.8944 –
Diameters [mm]
Diameter Dact
Q.8960 –
Diameter Dact
Q.8961 –
D = actual diameter
act
Amperages [A]
Compensation component Isq Reference
Q.8982 –
Current limitation from web tension limitation
Q.8981 –
Torques [Nm]
Torque limitation from web tension limitation
Q.8980 –
7

Actual values

No.
Actual Value Diameter Dact
841
Speed Factor
842
Torque Factor
843
Gear Factor Linefreq. to Winderfreq. at Dmin
844
40
(filtered)
(filtered with P.895)
(filtered with P.895)
(filtered with P.895)
Actual value parameter
Description
ACU
Winding Drive
T I elsto.eu
+31(0)88 7865800
Unit Chapter
mm 5.2.5
% 5.2.5
% 5.2.5
- 5.2.5
