5.5.2.3

Limit for detection of acceleration process

Minimum Deviation for Comp. Acceleration
Via Parameter
process is detected. Acceleration pre-control via Parameters 870 and 871 will only be activated when
the deviation between ramp input and ramp output is greater than Parameter 869.
Parameter 869should be set such that small variations of the reference speed do not result in narrow
"needles" in the reference torque. Minor reference value variations normally are no intended change
of the reference value, but are caused by noise in the analog reference value or changing diameters in
operation.
Parameter
No. Identifier
Minimum Deviation for Comp. Accel-
869
eration
5.5.2.4

Current limitation

Current Limit for Compensation
Via Parameter
compensation calculator can be limited. The compensation calculator outputs a torque-forming current
component, Parameter 872 only refers to this component.
The total current is set accordingly, depending on the parameterized magnetizing current and the
output of the speed controller. The outputs of the compensation calculator and speed controller to-
gether form the reference value
Parameter
No. Identifier
Current Limit for Compensation
872
5.5.3

Output of compensation calculator

The output of the compensation calculator is a current which, together with the output of the speed
Isq Reference
controller, forms
Amperages [A]
Compensation component Isq Reference
Q.8982 –
11/13
T
+31(0)88 7865800
Unit
Hz
872, the reference current which is output by the
Isq Reference
for the torque-forming current component.
Unit
A
.
ACU
Winding Drive
I elsto.eu
869, you can set when an acceleration
Setting range Default settings
0.00 .. 999.99
Setting range Default settings
0.0 .. 12.0
1.00
2.8
