Frequency source for winder drive
The source for the actual frequency is selected via Parameter
Parameter
No. Identifier
Source Actual Value Speed
885
Minimum frequency for diameter calculation
Below the frequency set in Parameter
tion is stopped because it can become very inaccurate with small values.
The value of the parameter should be below the frequency reached in normal winding operation at
maximum diameter. However, it should not be below 5% of the maximum frequency.
Parameter
No. Identifier
Minimum Frequency for Calculation
886
Presetting the diameter upon coil replacement
Following coil replacement, the diameter should be preset to D
logic sources in Parameters
parameter has value TRUE, the diameter is preset to D
tion. The diameter is maintained at the preset value as long as the signal is TRUE
Parameter
No. Identifier
Reset Dact to Dmin
889
Reset Dact to Dmax
890
5.2.4

Output values

The output values can be obtained from the following sources:
Diameter values [mm]
Q.8960 – diameter unfiltered
Q.8961 – diameter filtered
Percentages [%]
Speed Factor at Dact
Q.8941 –
Speed Factor at Dact
Q.8942 –
Torque Factor at Dact
Q.8943 –
Torque Factor at Dact
Q.8944 –
Q.8941 outputs 100% if the current diameter is the minimum diameter. With increasing diameters,
the speed will decrease. Q.8941=D
Q.8941 outputs 100% if the current diameter is the maximum diameter. With decreasing diameters,
the torque to be applied will decrease. Q.8943 =D
Boolean values
Coil Size Limit Reached
Q.8925 –
