5.2.2 Parameters for Operation Mode 1 – Sensor
The diameter sensor is typically connected to one of the analog inputs of the frequency inverter (0-
10V). Thus, the diameter is available to the Diameter Calculator as a percentage (e.g. 0-100%).
Percentage source
The source for the percentage is selected via Parameter
Parameter
No. Identifier
Source Diameter-Sensor
892
Percentages at minimum and maximum diameter
The percentages at minimum and maximum diameter are set via Parameters
Dmin Percentage Value at Dmax
893 and
Dmin
rameters 887 and
"Parameters for both operation modes".
Parameter
No. Identifier
Percentage Value at Dmin
893
Percentage Value at Dmax
894
It must be noted that the characteristic of the analog inputs are included in the calcula-
tion of the percentage.
Percentages at D
analog inputs during commissioning by reading Parameters
S1INA
251 and
full.
5.2.3 Parameters for Operation Mode 10 – Estimation
In this operation mode, the diameter is calculated from the quotient of the line speed and the winder
speed.
The line speed can be determined without slip at a clamping roll equipped with a speed sensor, for
example. The speed sensor is connected to the winder frequency inverter as Speed Sensor 2 and the
Division Marks are set correctly.
Frequency source for line speed
Source Line Speed
Via Parameter
ample above). Frequency sources may also be frequencies received via System Bus or an analog sig-
nal.
Parameter
No. Identifier
Source Line Speed
882
11/13
Unit
-
894. The minimum and maximum diameter are set in Pa-
Dmax
888, see Chapter Fehler! Unbekanntes Schalterargument.
Unit
%
%
and D can be taken from the actual value parameters of the
min max
Analog Input EM-S1INA
882, the frequency source is selected (the speed sensor in the ex-
Unit
-
ACU
Winding Drive
T I elsto.eu
+31(0)88 7865800
Source Diameter-Sensor
Setting range
Source percentage table
Setting range
-300.00 .. 300.00
-300.00 .. 300.00
253 when the winder is empty and when it is
Setting range
Source-frequency table
892.
Default settings
52 – Analog Input
MFI1A
Percentage Value at
Default settings
0.00
100.00
Analog Input EM-
Default settings
9 - zero
