Release
The actual diameter value is determined only if the logic source selected in Parameter
ter Calculation
881 has value TRUE.
Parameter
No. Identifier
Enable Diameter Calculation
881
Gear box at winder drive
Gear Box: Driving Shaft Revolutions
With Parameters
tions
897, a gear box at the winder drive can be considered.
Parameter
No. Identifier
Gear Box: Driving Shaft Revolutions
896
Gear Box: Motor Shaft Revolutions
897
Filtering the diameter
Filter time constant
With Parameter
diameter to obtain filtered diameters.
Parameter
No. Identifier
Filter time constant
895
It must be noted that the filters for the analog inputs are active, too. Thus, the per-
centage used for calculation of the diameter is already filtered.
Error message diameter is above/below given diameter value
Mode Diameter Limit Message
With Parameter
when the diameter is above/below the diameter value set in Parameter
If the diameter is above/below the required value, a message is generated via sources Q.8925 and
Q.8926, if applicable, in order to announce that the coil has to be replaced, for example. Q.8925
refers to the unfiltered diameter, Q.8926 to the filtered diameter.
Parameter
No. Identifier
Mode Diameter Limit Message
898
Limit Diameter Message
891
Operation Modes of Parameter 898
0 - off
1 - Message below Limit
2 - Message above Limit
28
T
+31(0)88 7865800
Unit Setting range
- Sources logic table
896 and
Unit Setting range
-
-
895, you can set up a PT1 filter. This filter can be applied to the
Unit Setting range
ms
898, you can set if a message is to be generated
Unit Setting range
-
mm
No message if value is below/above Parameter 891.
Message is generated if value is below Parameter
891.
Message is generated if value is above Parameter
891.
ACU
Winding Drive
I elsto.eu
Default settings
161 - Run Signal
Gear Box: Motor Shaft Revolu-
Default settings
1 .. 65535
1 .. 65535
Default settings
8 .. 32000
Limit Diameter Message
Default settings
0, 1, 2
5 .. 65530
Enable Diame-
1
1
32
891.
0 - Off
90
