5.5.2

Compensation of acceleration torque

The torque of the drive required for acceleration is defined by the moment of inertia of the system
which is made up of a constant and a diameter-dependent component.
The torque is determined "experimentally" after setting the parameters mentioned before, with deac-
tivated speed controller (limitation of speed to 0).
5.5.2.1

Compensation of constant acceleration torque

For compensation of the constant component of the acceleration, a mechanical time constant is set in
Mech. Time Constant at Dmin
[ms] in Parameter
torque) to accelerate the empty winder to rated speed.
Parameter
No. Identifier
Mech. Time Constant at Dmin
870
Adjustment Parameter 870
• To identify and verify the value, accelerate the empty winder.
Mech. Time Constant at Dmin
First, set Parameter
•
• The frequency ramp is to be set to the highest value occurring in operation at which the output
figure of the speed controller is not yet limited.
Minimum Deviation for Comp. Acceleration
Set Parameter
•
detection of acceleration process") to 50% of the set acceleration ramp. In this way, it is ensured
that the acceleration pre-control becomes active.
Mech. Time Constant at Dmin
• Increase Parameter
needs (at rated torque) to accelerate the empty winder to rated speed.
11/13
T
+31(0)88 7865800
870. This is the time the drive needs (at rated
Unit Setting range
ms 0 .. 60000
870 to the minimum value.
870 until the time is reached which the drive
ACU
Winding Drive
I elsto.eu
Default settings
869 (see Chapter 5.5.2.3 "Limit for
0
