ADDER AdderLink iPEPS User Manual page 32

Advanced Settings
This option contains video signal settings that do not normally need to be
adjusted.
Pixel Format
Determines the colour
depth and data
required to represent
each video pixel.
Motion Detection
This option is not
available for use with
the iPEPS.
Overlap Capture
When enabled, the iPEPS will begin capturing the
next frame of video output from the host computer
before it has fully completed processing the current
frame. In most cases this produces better video
performance, however, when moving large objects
around the screen (such as an application window),
the video image seen at the remote system may
exhibit temporary artifacts as the large image
moves.
Tile Width and Height
Determines the size of the sample
areas into which the source video
screen is divided for examination
purposes. Smaller sizes result in
more areas to sample, larger areas
result in more frequent screen area
refreshes. 16 is considered to be the
optimum size for both the width
and height settings.
Virtual Media
Please see the next page for details.
Info
When selected, this option displays an information dialog showing the current
logged on users, the current host, its video mode and its mouse motion details.
