Target Narrow bookcase canarrbkes Assembly Instructions Manual page 12

step 6.
(H1) x 6 (H5) x 3
cam wooden dowel
1. Attach parts L to parts O. Refer to page 6 for instructions on how to use the cam lock system.
2. Insert shelf supports into desired hole. Different holes accommodate different shelf heights
3. Angle shelves to fit between the rails and set on top of shelf supports.
12
L
x3
O
(H4) x 6 (H2) x 12
cam bolt
shelf support
O
O
O
