narrow bookcase
style # CANARRBKES (espresso)
dpci # 249-14-0039
tcin # 13556948
style # CANARRBKEB (ebony)
dpci # 249-14-0041
tcin # 13556950
style # CANARRBKMT (midtone cherry)
dpci # 249-14-0366
tcin # 13556937
style # CANARRBKCH (chestnut)
dpci # 249-14-0359
tcin # 13556942
style # CANARRBKWH (white)
dpci # 249-14-0363
tcin # 13556940
style # CANARRBKBR (rustic)
dpci # 249-14-5419
tcin # 53587258
>> assembly instructions
style # CANARRBKGY (gray)
dpci # 249-14-5356
tcin # 53587259
style # CANARRBKWL (walnut)
dpci # 249-14-5357
tcin # 53587257
© 2019 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
Advertisement
Related Manuals for Target CANARRBKES 249-14-0039
Summary of Contents for Target CANARRBKES 249-14-0039
- Page 1 # 13556942 style # CANARRBKWH (white) dpci # 249-14-0363 tcin # 13556940 style # CANARRBKBR (rustic) dpci # 249-14-5419 tcin # 53587258 >> assembly instructions © 2019 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
- Page 2 Congratulations on your latest Target purchase. Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you. All you need to do is follow our simple instructions and you’ll be on your way to transforming your room in no time.
- Page 3 table of contents introduction hardware parts list how to use the cam lock system assembly 7-13 QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.
- Page 4 hardware (H1) x 27 (H2) x 12 (H3) x 1 (H4) x 27 (H5) x 20 shelf support wall anchor cam bolt wooden dowel (H6) x 27 (H7) x 4 (H8) x 1 (H9) x 1 (H10) x 1 short pan head screw small flat head screw 38mm wall screw wall strap...
- Page 5 exploded diagram ITEM DESCRIPTION QUANTITY middle back fixed stretcher top front stretcher decorative molding middle front fixed stretcher adjustable shelf stretchers bottom front stretcher adjustable shelves middle fixed shelf bottom panel back panel right side panel left side panel top panel...
- Page 6 how to use the cam lock system Screw cam bolt into panel Align cam bolt(s) with cam(s) Push cam into panel - arrow feature and insert all the way into on cam top points to panel edge cross-bored hole(s) Rotate cam(s) clockwise 180° to Panels should be tight against each lock panels together other and connection should be rigid...
- Page 7 step 1: prepare fixed shelves. attach shelves and top front rail to left side panel. (H1) x 11 (H5) x 9 (H4) x 11 wooden dowel cam bolt 1.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. Carefully tap small wooden dowels into place.
- Page 8 step 2: attach right side panel (H1) x 5 (H5) x 6 (H4) x 5 wooden dowel cam bolt 2.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 2.2.
- Page 9 step 3: attach decorative molding (H7) x 4 small flat head screw 3.1. Align screws with pre-drilled holes. 3.2. Do not over tighten screws.
- Page 10 step 4: attach top panel (H1) x 5 (H5) x 2 (H4) x 5 wooden dowel cam bolt 4.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 4.2. Screw-In cam bolts must be screwed down flush. 4.3.
- Page 11 step 5: attach back panel pre-drilled holes hole for anti-tip Begin by installing all of the screws along one edge of the back panel. Next, using a square or tape measure, make sure that the cabinet is square. (If using a tape measure, the distance from one corner, diagonally to the other corner should be the same in both directions.) If not, apply gentle pressure to the diagonally opposite...
- Page 12 step 6: attach adjustable shelf stretchers to adjustable shelves then install (H1) x 6 (H5) x 3 (H4) x 6 (H2) x 12 wooden dowel cam bolt shelf support 6.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. Carefully tap small wooden dowels into place.
- Page 13 step 7: install anti-tip kit (H11) (H9) (H3) Position against wall (H10) Mark position of strap hole on Mark position of strap hole on wall wall Drill 1/4’’ hole Tap in wall anchor Fasten anti-tip strap Fasten anti-tip strap with flat-head screw provided with flat-head screw provided (H8) (H11)
- Page 14 1. This unit has been designed for the weight shown. Exceeding this recommended weight could result in excessive “sagging” of the top. Extreme overloading can cause failure of the top and possible injury. 2. Furniture Care Instructions: Dust with a clean, lint-free cloth. Use a spray furniture polish as needed. QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service.
- Page 15 © 2019 Target. The Bullseye Design is a trademark of Target Brands, Inc. All rights reserved.
