step 4.
(H1) x 5
(H5) x 2
cam
wooden dowel
1. Carefully tap small wooden dowels into place. Leave 1/2" of the dowels sticking out.
2. Screw-In cam bolts must be screwed down flush with wood panel.
3. Refer to page 6 for instructions on how to use the cam lock system.
10
(H4) x 5
cam bolt
Z
