Hand Tool for PV Solar Pin and Socket Crimp Terminals
Tool Kit
Order No. 63823-6470
FEATURES
A full cycle ratcheting hand tool ensures complete crimps
%
Ergonomically designed soft handles
%
Precisely designed crimping profiles with simple contact positioning
%
Easy handling due to outstanding force ratio
%
Tool kits are easily installed into the Hand Crimp Tool or the 63816-0300 Power Crimp Head which is installed
into the 63816-0200 (110 V) or the 63816-0250 (220 V) Battery Powered Tool.
Many different Tool kits can be used with a single Battery Powered Tool.
This tool is IPC/WHMA-A-620 Class 2 and RoHS compliant.
SCOPE
Products: PV Solar Pin and Socket Crimp Terminals, 10-14 AWG (6.0-2.5mm²)
Terminal
Terminal Order No.
Series No.
Loose
130196-0310 130196-0314
130196
130196-0313 130196-0315
130197-0325 130197-0346
130197
130197-0336 130197-0347
93302-0006
93302
93302-0005
93303-0005
93303
93303-0006
DEFINITION OF TERMS
STRIP LENGTH
BELL MOUTH
WIRE
The above terminal drawing is a generic terminal representation. It is not an image of a terminal listed in the
scope.
Doc No: ATS-6382364HM Release Date: 03-04-11
Revision: C
Application Tooling
Specification Sheet
Wire Size and Type
Reel only
AWG
10-12
14
10-12
14
93302-0004
10-12
93302-0003
14
93303-0003
10-12
93303-0004
14
Customer to cut off terminal from reel: 0.50mm (.020") maximum Cut-off Tab.
CONDUCTOR
CUT-OFF
CRIMP
TAB
Revision Date: 01-03-12
Insulation Diameter (ref)
mm²
mm
6.00-4.00
7.8
2.50
6.7
6.00-4.00
7.8
2.50
6.7
6.00-4.00
7.8
2.50
6.7
6.00-4.00
7.8
2.50
6.7
CONDUCTOR
BRUSH
SEAM
UNCONTROLLED COPY
TYPE 4C
Hand Crimp Tool
Order No. 63823-6400
Strip Length
In.
mm
.31
7.00-10.00 .276-.394
.26
7.00-10.00 .276-.394
.31
7.00-10.00 .276-.394
.26
7.00-10.00 .276-.394
.31
7.00-10.00 .276-.394
.26
7.00-10.00 .276-.394
.31
7.00-10.00 .276-.394
.26
7.00-10.00 .276-.394
BEND
UP
ROLLING
TWISTING
BEND
DOWN
In.
Page 1 of 8
