Infragas-109 - Infragas-209 - Infragas-309 - Infragas-205 - Infragas-305
Operation and maintenance manual
4 INSTALLATION
Installation is easy and can be performed by the user or, if required, by Assemblad
authorized personnel.
4.1 TRANSPORT AND INSTALLATION
Due to small dimensions of the equipment, transportation can be done by hand, take care
to particularly avoid crashes or falls, damages caused for these reasons are not covered
by warranty.
It is suggested to keep the original package in case of future shipment for periodic
calibration, technical assistance, etc.
If a trolley has been supplied together with the equipment, it must be put over with care in
order to guarantee stability during movements, on the trolley shelf and supports it is
possible to place all the accessories needed for its use.
Connect the optional Universal RPM Counter to the external RPM plug or to the dedicated
RPM serial port on the rear panel, connect the Oil temperature probe to the Oil Temp
plug, connect the Gas probe to the condense separator input.
For motorcycle equipment connect compressed air line (maximum pressure setting is 4
bar) to the dedicated connector-plug.
Metrological logbook must be kept in a secure place and showed to the technical
personnel for periodic control or to National Inspectors for verification. The buyer is legally
responsible for the correct preservation from loss and/or damage. ASSEMBLAD decline
every responsibility in case of what said above is not observed.
4.2 CONNECTION TO POWER SUPPLY
Infragas 109 – Infragas 205 – Infragas 305
Connect the equipment to a power supply plug, at 220 Vca. 50 Hz., using the 12V power
adaptor supplied and verify that such values correspond to the ones indicated on the rear
label. Put the power button in the ON position to switch on the equipment.
Infragas 209 – Infragas 309
Press the switch in position [-] (upwards) for at least one second to switch it on or in
position [=] (downwards) to switch it off. The instrument will automatically shut off when
the battery falls below the guard level. Approaching this level will be signalled by an
acoustic alarm.
ASSEMBLAD S.r.l. - 50013 Campi Bisenzio - Firenze - Italia
25
www.assemblad.com - info@assemblad.com
