2 TECHNICAL DATA

RANGE AND RESOLUTION
CO
CO2
HC
O2
RPM
Oil Temp.
Int. Temp.
Amb. Press.
NOx
CO corr.
Lambda
OPERATIONAL CHARACTERISTIC
Response Time
Warming Time
Temperature range
Supply
Power
Barometric pressure
Gas flow
Compressed air (*)
Periodic calibration
Dimensions
Weight without pipe
RANGE
0 ÷
0 ÷
0 ÷
0 ÷
0 ÷
0 ÷
0 ÷
800 ÷
(*) 0 ÷
0 ÷
0.500 ÷
- 20 sec. max
- 2 min. typical
- 0 °C ÷ + 40 °C
- 9 ÷ 16 Vcc
- 30 W max
- 850 ÷ 1060 mbar
- 3 l/min
- from 2 to 4 bar
- 12 months max.
- 263x155x84 mm (Infragas-109)
- 290x198x168 mm (Infragas-209/309)
- 344x160x270 mm (infragas-205/305)
- 3,0 Kg about (Infragas-109)
- 6,8 Kg about (Infragas-209/309)
- 4,2 Kg about (Infragas-205/305)
