Infragas-109 - Infragas-209 - Infragas-309 - Infragas-205 - Infragas-305
LIMITS SETTING
1 – Max RPM at minimum rate:
2 – Min RPM at accel.
3 – Max RPM at accel.
4 – Max COcorr at min. rate:
5 – Max COcorr at acc. rate:
6 – Max Lambda
7 – Min Lambda
Acceptable limits of the test are set in accordance with the vehicle data entered.
It is possible, however, to edit such limits pressing the corresponding key, delete the
present limit, enter a new value and press OK to confirm.
In case of no catalytic vehicle some limits will not be present because they are not
requested for the test execution.
Press ESC to go back to the main menu.
INSTRUMENTS
Press the corresponding numeric key to select the instrument you want to use then press
OK to confirm.
If you need to connect and/or control the equipment with a PC you must select 'REMOTE'.
With this selection the PC will be able to communicate with the internal gas analyser and
with the connected smoke meter and RPM.
LIMITS SETTING
INSTRUMENTS
1 – ANALYSER
2 – SMOKEMETER
3 – RPM
4 – SPEED TESTER
5 - REMOTE
