3.9 DISPLAY AND MENU

The gas analyser INFRAGAS-205 has a display to show the menu and the measurement.
Some part may be not enabled, some other reserved for technical service.
MAIN MENU
26/06/06
This menu is displayed when we turn on the instrument and when we come-back from
other menu.
In the high-left corner is showed the data, in the upper centre is reported the selected
instrument, to operate the choice push the key-number.
After a short time the backlight is switched-off, push the ESC key to restore.
Use the arrow keys to set the contrast of the LCD, this function work only in this menu.
AMBIENT DATA
Use this menu to enter ambient data.
These data must be read from a dedicated instrument and they will be printed onto the
test result report.
Press ESC to go back to the main menu.
INFRAGAS-205
1 – VEHICLE DATA
2 – AMBIENT DATA
3 – LIMITS SETTING
4 – INSTRUMENTS
-------------------
5 – MAINTENANCE
6 - LANGUAGE
AMBIENT DATA
1 – Temperature
2 – Amb. pressure : 1000hP
3 – Rel. humidity :
4 – Wind speed
