Quick Links
marketplace
INDEX
By Section
Product
Product Name
Code
CHASSIS
End Gable
UMCE
Truss
UMCT
Travers
UMCV
BODY
End Worksurface
UMWE
In-Line Worksurface
UMWI
Modesty Panel
UMWM
End Worksurface Single Sided
UMWN
In-Line Worksurface Signle Sided
UMWL
Auxiliary Worksurface
UMWA
Privacy Angles
UMSP
Insert - Accessory Rail
UMSI
Center - Mount Screen
UMSC
Casual - Center Mount Screen
UMSM
Lateral Screen
UMSL
Canopy
UMQC
Canopy Light
UMQL
Base Feed
UMQB
Power/Communications Box -
UMQP
Truss Mounted
Recessed Power/Communication Box
UMQR
Power/Communications Box -
UMQT
Table Mounted
Wire Tray
UMQW
January 2018
*Click on the desired Installation Guide to jump to the Guide
page.
Guide
Last
No.
Updated
001
Jul 2015
002a
Jul 2015
002b
Jul 2015
002c
Jun 2017
003
Jul 2015
004
Jul 2015
005a
Jul 2015
005b
Jul 2015
005c
Dec 2017
006
Jul 2015
007
Jul 2015
008
Jul 2015
009a
Jul 2015
009b
Jul 2015
010
Jul 2015
PAGE 1 OF 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Teknion marketplace Series
Summary of Contents for Teknion marketplace Series
- Page 1 marketplace *Click on the desired Installation Guide to jump to the Guide INDEX page. By Section Product Guide Last Product Name Code Updated CHASSIS End Gable Jul 2015 UMCE Truss UMCT Travers UMCV BODY End Worksurface 002a Jul 2015 UMWE In-Line Worksurface UMWI Modesty Panel...
- Page 2 marketplace Section: Date: July 2015 Page No: 1 of 10 Description: MP_001 Rev. No: 1 End Gable Exploded View (UMCE) Part and Product Identification - Plastic Corner Cap (B02-0237) x4 - Bottom Trim Cap (B02-0236) x4 - 5/16 - 18 x 1" SBHC (E01-0651) x8 - Gable End Trim (A23-1658) x4...
- Page 3 marketplace Section: Date: July 2015 Page No: 2 of 10 Description: MP_001 Rev. No: 0 Single Sided End Gable Exploded View (UMCE38) Part and Product Identification - Plastic Corner Cap (B02-0237) x4 - Bottom Trim Cap (B02-0236) x4 - 5/16 - 18 x 1" SBHC (E01-0651) x8 - Gable End Trim (A23-1658) x4...
- Page 4 marketplace Section: Date: July 2015 Page No: 3 of 10 Description: MP_001 Rev. No: 0 Truss and Traverse Exploded View (UMCT, UMCV) Part and Product Identification - Truss (N09-1602) x2 - Half Spacer (A18-0111) x6 - M10x1.5x16mm Hex Bolt, Zinc (E03-0461) x6 - Washer, Zinc (E03-0469) x6...
- Page 5 marketplace Section: Date: July 2015 Page No: 4 of 10 Description: MP_001 Rev. No: 0 Single Sided Truss and Traverse Exploded View (UMCT, UMCV) Part and Product Identification - Truss (N09-1602) Quantity Varies - Half Spacer (A18-0111) x6 - M10x1.5x16mm Hex Bolt, Zinc (E03-0461) x6 - 3/8"...
- Page 6 marketplace Section: Date: July 2015 Page No: 5 of 10 Description: MP_001 INSTALL SUPPORT GLIDER INSTALL HEX BOLTS STEP 1: Install Support Glider at both ends of the End Gable Frame. INSTALL BOTTOM TRIM CAPS Detail View Side View STEP 2: Install Bottom Trim Cap at both ends. Adjust Trim Cap for centering and use Trim STEP 3: Slide in Hex Bolts into Top and End Trims.
- Page 7 marketplace Section: Date: July 2015 Page No: 6 of 10 Description: MP_001 INSTALL GABLE END TRIMS INSTALL PLASTIC CORNER CAP Underside View Detail View STEP 4: Once Hex Bolts are in place, install Gable End Trims and secure with the Hex Nut STEP 5: Install Plastic Corner Cap onto Top Trim.
- Page 8 marketplace Section: Date: July 2015 Page No: 7 of 10 Description: MP_001 TRUSS NO LEG INSTALLATION 20" NO LEG TRUSS INSTALLATION STEP 8a: Install Truss Spacer into Truss Assembly. STEP 8b: Install Truss Spacer and Truss Spacer Wedge into Truss Assembly. 20"...
- Page 9 marketplace Section: Date: July 2015 Page No: 8 of 10 Description: MP_001 FASTEN TRUSSES POSITION & LEVEL ASSEMBLY Left Truss Right Truss Approx. 1-3/4" Default STEP 10: Use Screws and Washers provided to fasten Trusses onto End Gables. STEP 11: Position and level the Truss and Gable Assembly.
- Page 10 marketplace Section: Date: July 2015 Page No: 9 of 10 Description: MP_001 ATTACH TRAVERSE CHANNELS SECURE TRAVERSE CHANNELS Plan View 5'-0" 5'-0" 5'-0" or 6'-0" or 6'-0" or 6'-0" STEP 12: Place Traverse in right location as shown. STEP 13: Use U-Bolt provided to fasten Traverse onto Truss. Hand tighten for further adjustments.
- Page 11 marketplace Section: Date: July 2015 Page No: 10 of 10 Description: MP_001 FASTEN GABLE INNER COVER INSTALL ACCESS COVER Detail View Underside View STEP 14: Use Screws provided to fasten Gable Inner Cover to Gable Frame. STEP 15: Install Access Cover onto Gable Inner Cover. FASTEN OUTER COVERS INSTALL LABEL STEP 16: Use Screws provided to fasten Gable Outer Cover onto Gable Frame.
- Page 12 C - Ledge Cover (A15-7207) x2 Shipped with (UMCE) D - 0.0656" Flat Washer (E03-0433) - 5/8" Steel Hex Nut (E03-0431) - Leveling Jack Screw (A18-0097) Quantity Varies with table width Double Sided Application Shown For Customer Support please contact product.support@teknion.com...
- Page 13 marketplace Section: Date: July 2015 Page No: 2 of 2 Description: MP_002a INSTALL LEVELING JACK SCREWS LEDGE COVER Chat Channel STEP 2: Lay Leger Cover on the top of End Gables, both sides. NOTE: For no gap installation of Worksurfaces 30" and 36" wide, repositioning of Hat Channel is required.
- Page 16 C - 0.0656" Flat Washer (E03-0433) Qty. varies with table width D - 5/8" Steel Hex Nut (E03-0431) Qty. varies with table width E - Leveling Jack Screw (A18-0097) Qty. varies with table width For Customer Support please contact product.support@teknion.com...
- Page 17 marketplace Installation Guides Section: BODY Date: Jun 2017 Page No: 2 of 2 Description: END AND IN-LINE (SINGLE) WORKSURFACE INSTALLATION MP_002c INSTALL LEVELING JACK SCREWS FASTENING WORKSURFACES Leave loose for leveling adjustment. STEP 1: Place Worksurface upside down. Insert 4 Leveling Jack Screws into Hat Channel STEP 2: Fasten Worksurface onto Traverse and End Gable.
- Page 28 marketplace Installation Guides Section: BODY Date: Dec 2017 Page No: 1 of 2 Description: LATERAL SCREEN MP_005c Rev. No: 2 Lateral Screen Installation (UMSLT, UMSLTS) Part and Product Identification A - Lateral Screen Tackboard (UMSLT) Worksurface Or Lateral Screen Wood (UMSLS) B - #10x0.875"...
- Page 29 marketplace Installation Guides Section: BODY Date: Dec 2017 Page No: 2 of 2 Description: LATERAL SCREEN MP_005c CONNECT LATERAL SCREEN SECURE TO WORKSURFACE Worksurface Worksurface Detail View STEP 1: Connect Lateral Screen onto worksurface as shown STEP 2: Fasten to worksurface using the screws the provided...
