MA273 (de_en)
Montageanleitung
PV-Kupplungsbuchse PV-KBT4-EVO 2
PV-Kupplungsstecker PV-KST4-EVO 2
MC4-Evo 2
Inhalt
Einleitung �����������������������������������������������������������������������������������1
Crimpen �������������������������������������������������������������������������������������8
Montageprüfung �����������������������������������������������������������������������9
Leitungsführung ����������������������������������������������������������������������10
Technische Daten ��������������������������������������������������������������������11
Notizen ������������������������������������������������������������������������������������12
PV-KBT4-EVO2/...
Einleitung
MC4-Evo 2 Steckverbindungen garantieren hohe Schutz-
klassen IP65 und IP68� Die Verriegelung der Steckverbinder
nach NEC 2014 durch den Locking type-Verschluss garantiert
höchste Anschlusssicherheit und ist nur mit dem Werkzeug
PV-MS-PLS/2 entriegelbar�
MA273 (de_en)
Assembly instructions
PV female coupler PV-KBT4-EVO 2
PV male coupler PV-KST4-EVO 2
MC4-Evo 2
Content
Introduction �������������������������������������������������������������������������������1
Appropriate use �������������������������������������������������������������������������4
Tools required ����������������������������������������������������������������������������5
Cable preparation ����������������������������������������������������������������������6
Crimping ������������������������������������������������������������������������������������8
Assembly check ������������������������������������������������������������������������9
Cable layout �����������������������������������������������������������������������������10
Technical Data �������������������������������������������������������������������������11
Notes ���������������������������������������������������������������������������������������12
PV-KST4-EVO2/...
Introduction
MC4-Evo 2 plug connectors guarantee high protection classes
of IP65 and IP68� The locking system of the plug connectors in
accordance with NEC 2014 guarantees optimum connection
security� Unlocking can be effected only with the tool
PV-MS-PLS/2�
1 / 12
