SPITFIRE MX
INCLUDED AIR RETRACTABLE LANDING GEAR.
AIR UP, AIR DOWN WITH OLEO STRUTS.
ALL BALSA - PLY WOOD CONSTRUCTION.
COVERED IN A HEAT-SHRINK FILM WITH PRINTED.
95% ALMOST READY TO FLY
SPECIFICATION:
- Wingspan: 2,000 mm 78.74 in.
- Length: 1,730 mm 68 in.
- Weight: 7.2 kg 15.8 lbs.
- Wing area: 75 dm .
- Wing loading: 96 g/dm .
- Wing type: Naca Airfoil.
- Servo mount: 42mm x 21mm.
- Gear type: Air retract gear with
oleo struts for main gear and
oleo struts for tail gear (included).
Instruction Manual Book
Parts listing required (not included):
- Radio: 07 channels.
- Servo: 09 standard high torque servos.
- Engine: 30 - 35 cc Gas.
- Motor: Brushless outrunner 2500 - 3200W, 250KV.
- Propeller: Suit with your engine.
Recommended Motor and Battery set up
(not included):
- Motor: RIMFIRE.1.60.
- Lipo cell: 12 cells 4,000-5,500mAh.
- Receiver battery: 6V/ 1200mAh.
- ESC: 80-100A.
Item code: BH136
Glow and EP
Made in Vietnam.

Advertisement

Table of Contents
loading

Related Manuals for Black Horse Model SPITFIRE MX

Summary of Contents for Black Horse Model SPITFIRE MX

  • Page 1 Instruction Manual Book Item code: BH136 SPITFIRE MX INCLUDED AIR RETRACTABLE LANDING GEAR. AIR UP, AIR DOWN WITH OLEO STRUTS. ALL BALSA - PLY WOOD CONSTRUCTION. Glow and EP COVERED IN A HEAT-SHRINK FILM WITH PRINTED. 95% ALMOST READY TO FLY...

  • Page 2: Table Of Contents

    Thank you for purchasing Black Horse Model products. With over 18 years experience in production and fly testing, Black Horse Model is committed to bring the best quality products and good service to customers. Along with a team of creative engineers and skilled workers, we will always accompany with customers by our great experiences, fully enthusiasm...

  • Page 3: Warranty

    In that Black Horse Model has no control over the final assembly or material used for final assembly, SUGGESTION Black Horse Model is not responsible for loss of use , or other incidental or consequential damages. To avoid scratching your new airplane, do not...
  • Page 4 SPITFIRE MX Item code: BH136 Instruction Manual FLIGHT WARNINGS ADHESIVES AND REQUIRED TOOLS When ready to fly, first extend the transmitter aerial. Thin CA Switch on the transmitter. 30-minute epoxy Switch on the receiver. 6-minute epoxy Check that the wings are correctly fitted to the Threadlocker thread locking cement fuselage.
  • Page 5 SPITFIRE MX Item code: BH136 Instruction Manual • Officially designated AMA Air Show Teams (AST) are authorized to use devices and practices as defined within the Team AMA Program Document. (AMA Document #718.) (j) Not operate a turbine-powered aircraft, unless in compliance with the AMA turbine regulations. (AMA Document #510-A.)

  • Page 6: Parts Listing (Not Included)

    SPITFIRE MX Item code: BH136 Instruction Manual PARTS LISTING (NOT INCLUDED). Servo extension leads....2 pcs. 220mm ..4 pcs. 190mm ..4 pcs. Engine: 35 cc gas Propeller. Suit with your engine. Motor: RIMFIRE.1.60 LiPo. 6S - 22.2V- 4,000 - 5,500mAh.
  • Page 7 SPITFIRE MX Item code: BH136 Instruction Manual : Fuselage set(1a: Canopy; 1b: Pilot; 1c: Top Hatch Fuselage; : Fuel tank set(8a: Clunk; : Cowling set(5a). 1d: Antenna; 1e: Mirror; 1f: Centre stick). 8b: Stopper(three line). : Tail gear set. : Wing set (2a; 2b; 2c; 2d; 2e: Aluminium tube dihedral brace).
  • Page 8 SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE AILERON AND FLAP Flap 3x12mm 3x12mm Tp Screw 44mm Pinned hinge Tp Screw - - - - - - - - - - - 2 - - - - - - - - - - - - - 8...
  • Page 9 SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE AILERON AND FLAP SERVOS Using the thread as a guide and using masking tape, tape the servo lead to the end of the thread: carefully pull the thread out. When you...
  • Page 10 SPITFIRE MX Item code: BH136 Instruction Manual For Flap Servo approx.16mm 3x12mm Tp Screw 1.5mm Screw 3x12mm Tp Screw 3mm Hex Nut 3mm Flat Washer 3x12mm Cap Screw 2x10mm Tp Screw 1.5mm...
  • Page 11 SPITFIRE MX Item code: BH136 Instruction Manual For Aileron Servo 2 mm approx.16mm 3mm Flat Washer 3mm Hex Nut 3x12mm Cap Screw 1.5mm Screw 2x10mm Tp Screw 1.5mm Cut off shaded portion Drill holes using the stated. carefully. (in this case 1.5mm 1.5mm...
  • Page 12 SPITFIRE MX Item code: BH136 Instruction Manual Bottom View Tie the string Pull out servo cord with string. 2x10mm Tp Screw 2x10mm Tp Screw Aileron Aileron Aileron 3x12mm Tp Screw Horn 3x12mm Cap Screw Aileron Aileron Cut off shaded portion Drill holes using the stated.
  • Page 13 SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE AIR RETRACTABLE LANDING GEAR 3x20mm Socket Head Cap Screw - - - - - - - 8 3mm Spring Washer - - - - - - - - - - - 8...
  • Page 14 SPITFIRE MX Item code: BH136 Instruction Manual Bottom View...
  • Page 15 SPITFIRE MX Item code: BH136 Instruction Manual Bottom View 3x6mm Button Head Cap Screw...

  • Page 16: Installing The Plastic Part For Wings

    SPITFIRE MX Item code: BH136 Instruction Manual Bottom View INSTALLING THE PLASTIC PART FOR WINGS...
  • Page 17 SPITFIRE MX Item code: BH136 Instruction Manual Bottom View...
  • Page 18 SPITFIRE MX Item code: BH136 Instruction Manual Top View INSTALLING THE FUSELAGE SERVOS 1) Install the rubber grommets and brass collets into the elevator, rudder and throttle servos. Test fit the servos into the servo tray. Trim the tray if necessary to fit your servos.

  • Page 19: Installing Valve Control

    SPITFIRE MX Item code: BH136 Instruction Manual Fuselage Top View Elevator Servo Rudder Servo Valve Control Servo Throttle Servo Elevator Servo INSTALLING VALVE CONTROL 3 way conector 2 way conector Connector - - - 3 - - - 4 - - - 1...
  • Page 20 SPITFIRE MX Item code: BH136 Instruction Manual Adjust the throttle input Connector (transmitter throttle stick), 2x10mm throttle trim movement and the 4x4mm carburattor opening to the suitable position Linkage Pushrod wire stopper and screw in the 4x4mm set Screw Fuselage Top View...

  • Page 21: Installing The Horizontal Stabilizer

    SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE HORIZONTAL STABILIZER Ball link 44mm Pinned Hinge Bottom View - - - - 4 - - - - 6 Horn - - - - 2 2.6x980mm Push rod - - - - 2...
  • Page 22 SPITFIRE MX Item code: BH136 Instruction Manual Bottom View 3mm Hex Nut Horn Push rod Ball link 3mm Flat Washer 3x12mm Cap Washer...
  • Page 23 SPITFIRE MX Item code: BH136 Instruction Manual 3x12mm Cap scew Flash washer Push rod Ball link Servo tail 3mm Hex nut Top View Elevator servo...

  • Page 24: Installing The Vertical Stabilizer

    SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE VERTICAL STABILIZER Ball link 44mm Pinned Hinge - - - - 2 - - - - 5 Horn - - - - 1 2.6x980mm Push rod - - - - 1...
  • Page 25 SPITFIRE MX Item code: BH136 Instruction Manual 3mm Hex Nut 3mm Hex Nut Horn Push rod Ball link 3mm Flat Washer 3x12mm Cap Washer...
  • Page 26 SPITFIRE MX Item code: BH136 Instruction Manual 3x12mm Cap scew Flash washer Push rod Ball link Servo tail 3mm Hex nut Top View Rudder servo Rudder...

  • Page 27: Installing The Tail Gear

    SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE TAIL GEAR 1000mm Cable rod M3 Metal Clevis 3x16mm Cap Screw - - - - - 2 - - - - - - - 4 - - - - - - - 2...
  • Page 28 SPITFIRE MX Item code: BH136 Instruction Manual 3x15mm...
  • Page 29 SPITFIRE MX Item code: BH136 Instruction Manual M3 Metal Clevit 3mm Connector Cab rod Hex Nut Rudder servo...
  • Page 30 SPITFIRE MX Item code: BH136 Instruction Manual SECURE THE WING TO THE FUSELAGE 32x857mm Aluminium tube. - - - - 1 4x15mm Socket Head Cap Screw...

  • Page 31: Installing The Engine Mount

    SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE ENGINE MOUNT May be you also need to trim some wood from the tri-angle Using plate of plywood (supplied with the kit) mark the holes wood for the installation is easy.

  • Page 32: Installing The Engine

    SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE ENGINE 16x5mm Rubber Washer 12x60mm Aluminium 5mm Spring Washer - - - - - - - 4 - - - - - - - 4 - - - - - - - 4...

  • Page 33: Installing The Stopper

    SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE STOPPER Cut off shaded portion...

  • Page 34: Installing The Fuel Tank

    SPITFIRE MX Item code: BH136 Instruction Manual 5. When satisfied with the alignment of the stopper INSTALLING THE FUEL TANK assembly tighten the 3mm x 20mm machine screw until the rubber stopper expands and 1. Using a modeling knife, cut one length of silicon seals the tank opening.

  • Page 35: Installing The Throttle

    SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE THROTTLE direction. When the throttle stick is moved forward from idle to full throttle, the throttle barrel should also open and close using this motion. If not, reverse the direction of the servo, using the...

  • Page 36: Mounting The Cowl & Top Hatch

    SPITFIRE MX Item code: BH136 Instruction Manual MOUNTING THE COWL & TOP HATCH 3x12mm Tp Screw - - - - - - - 8 Plastic 01 - - - - - - 4 Plastic part - - - - 2...
  • Page 37 SPITFIRE MX Item code: BH136 Instruction Manual 3x12mm Tp Screw...

  • Page 38: Installing The Switch, Receiver And Battery

    SPITFIRE MX Item code: BH136 Instruction Manual Open / Close INSTALLING THE SWITCH, RECEIVER AND BATTERY 1) Plug the servo leads and the switch lead into INSTALLING THE SWITCH the receiver. You may want to plug an aileron 1) The switch should be mounted on the fuselage...

  • Page 39: Installing Canopy

    SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING CANOPY Position the canopy so the rear frame on the canopy is aligned with the rear edge of the cockpit opening. Use canopy glue to secure the canopy to the canopy hatch. Use...

  • Page 40: Installing The Propeller And Spinner

    SPITFIRE MX Item code: BH136 Instruction Manual Adhesive tape INSTALLING THE PROPELLER AND SPINNER 3x12mm TP Scew - - - 4...
  • Page 41 SPITFIRE MX Item code: BH136 Instruction Manual INSTALLING THE ELECTRIC MOTOR (EP MOTOR) M4 Blind Nut 10x20mm Aluminium 4x40mm Socket Head Cap Screw - - - - - 4 - - 4 M4 Blind Nut 4mm Flat Washer - - - - - 4...
  • Page 42 SPITFIRE MX Item code: BH136 Instruction Manual 5mm Rubber Washer 5mm Flat Washer 5mm Spring Washer 12x60mm 5mm Flat Washer 5x90mm 160mm...

  • Page 43: Balancing

    SPITFIRE MX Item code: BH136 Instruction Manual LATERAL BALANCE BALANCING 1. It is critical that your airplane be balanced correctly. After you have balanced a plane on the C.G. Improper balance will cause your plane to lose You should laterally balance it. Doing this will control and crash.

  • Page 44: Control Throws

    SPITFIRE MX Item code: BH136 Instruction Manual In order to obtain the CG specified, reposition the receiver and other equipment. If not obtain the CG specified, add a weight and adjust. Do not fly before confirming the correct location of the CG. If the...
  • Page 45 SPITFIRE MX Item code: BH136 Instruction Manual FOR YOUR RADIO INSTALLATION BASIC CONNECTION FOR AIRPLANE AND ADJUSTMENT OF SERVOS For more information, refer to radio system instruction manual. Example of connection Follow instruction manual of Engine and Battery. Aileron Servo...
  • Page 46 SPITFIRE MX Item code: BH136 Instruction Manual MAIN GEAR DIMENSIONAL DETAIL 72mm 60mm 41mm 6.1mm hold TAIL GEAR DIMENSIONAL DETAIL 23mm 31mm 18mm...
  • Page 47 SPITFIRE MX Item code: BH136 Instruction Manual...
  • Page 48 SPITFIRE MX Item code: BH136 Instruction Manual I/C FLYING WARNINGS Always operate in open areas, away from fly near power lines,aerials or AL WAYS adjust the engine from behind NEVER factories, hospitals, schools, buildings other dangerous areas including airports, the propeller, and do not allow any part of and houses etc.
  • Page 49 SPITFIRE MX Item code: BH136 Instruction Manual I/C FLYING GUIDELINES Operate the control sticks on the ALWAYS land the model INTO When ready to fly, first extend transmitter and check that the the wind, this ensures that the the transmitter aerial.
