Culligan CTM Series Installation, Operation, And Service Instructions With Parts Lists page 87

Item Part No.
Control Valve, Single Tank, Downflow, Hard
— 01028301
Water Bypass
Control Valve, Single Tank, Downflow, No
— 01028304
Hard Water Bypass
Control Valve, Multi Tank, Downflow, No
— 01028300
Hard Water Bypass
Control Valve, Timeclock, Single Tank,
— —
Downflow, No Hard Water Bypass
1 01029565 Kit, Brine Elbow Assembly
2 01000601 Insert, Refill Flow Control, 0.5 gpm
01000602 Insert, Refill Flow Control, 2.0 gpm
01000603 Insert, Refill Flow Control, 3.0 gpm
3 — Clip, Brine Adapter
4 P1028012 Clip, Drain Line Flow Adapter, 10 PK
Kit, Drain and Brine Line Flow Control, 60K
5 01029469
Units (Contains Items 2 and 6)
Kit, Drain and Brine Line Flow Control,
01029460
90K-600K Units (Contains Items 2 and 6)
Inserts, Drain Line Flow Control, 0 GPM,
6 P1028331
Black, 10 PK
Inserts, Drain Line Flow Control, 5 GPM,
P1028332
Blue, 10 PK
Inserts, Drain Line Flow Control, 6 GPM,
P1030741
Red, 10 PK
Inserts, Drain Line Flow Control, 8 GPM,
P1028333
Green, 10 PK
Inserts, Drain Line Flow Control, 10 GPM,
P1028334
Orange, 10 PK
7 01029581 No Hard Water Bypass Plug (for conversion)
8 01029564 Eductor Port Cap
Eductor Nozzle, Black, w/O-Ring, 0.28 gpm,
9 P1028311
10 PK
Eductor Nozzle, Violet, w/O-Ring, 0.58 gpm,
P1028313
10 PK
Eductor Nozzle, Red, w/O-Ring, 0.72 gpm,
P1028314
10 PK
Eductor Nozzle, White, w/O-Ring, 1.01 gpm,
P1028315
10 PK
Eductor Nozzle, Blue, w/O-Ring, 1.44 gpm,
P1028316
10 PK
Eductor Nozzle, Beige, w/O-Ring, 2.16 gpm,
P1028317
10 PK
Eductor Throat, Blue #4, w/O-Rings, 2.4
10 P1028318
gpm, 10 PK
Eductor Throat, Blue #5, w/O-Rings, 3.6
P1028319
gpm, 10 PK
Eductor Throat, Blue #3, w/O-Rings, 5.9
P1028320
gpm, 10 PK
Eductor Throat, Blue #8, w/O-Rings, X gpm,
P1028321
10 PK
11 — Clip, Eductor Plug Cap
12 01029567 Kit, Valve Clamp
13 P1023559 O-Ring, 10 PK
00401858 O-Ring (24", 30" & 36" Ported Tanks Only)
Cat. No. 01029401
Description
1
3
3
3
Item Part No.
14 P1023560 O-Ring, 10 PK
15 P1023558 Retainer Ring, 10 PK
16 01019742 Upper Disperser
17 01028328 Kit, Flow Meter Assembly
01028052 Kit, Coupler Assembly
18 01029566 Kit, PRV Assembly
19 P1028381 Coupling/Flow Meter O-Ring, 10 PK
20 — Clip, Vacuum Breaker/PRV
21 01029582 Vacuum Breaker & PRV Port Plug
22 01029580 Kit, Core Control Valve Replacement
23 01029584 Screws, Top Manifold
24 01029562 Motorized Ball Valve #1 (Ports 4, 5, 6)
25 01029563 Motorized Ball Valve #2 (Ports 1, 2, 3)
26 01029583 Pilot Valve Rebuild Kit
27 — Kit, Position Sensor
28 — Kit, Pilot Body and O-Rings
29 — Kit, Position Indicator Wheel
30 — Gear, Pilot Drive Spool, CTM
31 01029558 Kit, Motor Assy, CTM
32 01029560 Housing, Top, Pilot Body, Downflow
33 01029561 Kit, Enclosure, Pilot Drive
Kit, Piston Actuator w/O-Rings, Flow Valves
34 01029576
and T-Seals
35 01029577 Kit, Piston O-Rings and T-Seals
Kit, Seals for upper, lower and external
36 01029578
valve body
37 01029580 Valve Core Replacement Kit
38 01029500 1.5" NPT Inlet/Outlet Plumbing Adapter
1.5" NPT Inlet/Outlet Plumbing Adapter w/
01029502
Ports
01029512 1.5" BSPT Inlet/Outlet Plumbing Adapter
1.5" BSPT Inlet/Outlet Plumbing Adapter w/
01029514
Ports
01029501 2" NPT Inlet/Outlet Plumbing Adapter
2" NPT Inlet/Outlet Plumbing Adapter w/
01029503
Ports
01029513 2" BSPT Inlet/Outlet Plumbing Adapter
2" BSPT Inlet/Outlet Plumbing Adapter w/
01029515
Ports
39 00303177 Tubing, 1/4", PE Black, 1 ft. (for Pilot Valve)
00402184 Tubing, 1/4", PE Blue, 1 ft. (for Pilot Valve)
40 01030179 Cable Harness, Ball Valves, Valve Mount
Cable Harness, Ball Valves, Remote
01030177
Mount
1, 5
41 01028019 Kit, Clips (Contains Item 3, 4, 11, and 20)
Kit, Single to Multi Tank Manifold
42 01029550
Conversion
Multi-Tank Only
1
Not designed to operate with Timeclock Control Valves.
2
A part of a Kit
3
Timeclock Only
4
Not Shown
5
Description
2
4
2
3
and Pilot Enclosure
5
1
1
3
3
3
3
1, 5
5
CTM Parts List
5
5
83
