- Page 1 FrameOne Plus User Manual Translation of the original user manual...
-
Page 2: Copyright
Improper assembly by unauthorised personnel. Use of components and adaptations that do not originate from Steelcase. Third-party parts are not guaranteed to be designed and manufactured to meet the requirements of stress and safety. Plans from third party suppliers that have been proven to lead to misuse of the product. -
Page 3: Product
Legal notice Product The office furniture line FrameOne Plus by Steelcase is subject to continuous quality control during manufacture and distribution. This ensures fault-free functionality. The products are designed and manufactured according to the state of the art (in Germany at the time of construction) and recognised safety rules;... -
Page 4: Table Of Contents
Technical data ..............................9 Factory setting on delivery ..........................9 Components ..............................10 Accessories ..............................10 Overview of FrameOne Plus desk ........................11 Transport and storage......................12 Safety instructions ............................12 Interim storage ..............................12 Installation and assembly ....................13 Safety instructions ............................ - Page 5 Disclaimer of liability ..........................26 Cleaning and care ............................ 27 Disposal of the desk ......................28 Customer Service ......................29 Delivery, installation, instruction ........................29 Repairs and spare parts ..........................29 FrameOne Plus Manual -en- 2017 Page 5 of 29...
-
Page 6: About This User Manual
Steelcase assumes no liability and no warranty for damage or malfunctions resulting from non-compliance with the user manual. This user manual is part of the FrameOne Plus desk. It is only valid as a complete document. Even when reselling the desk, this user manual is part of the delivery contents. -
Page 7: Safety Instructions And Warnings
Indicates a potential danger situation that may result in minor injuries if the safety precautions are not followed. NOTICE Danger Source of danger Prevention measures Warning of property damage or malfunction if safety precautions are not followed. FrameOne Plus Manual -en- 2017 Page 7 of 29... -
Page 8: Safety
Safety Safety Intended use The desk FrameOne Plus is designed exclusively for use as office furniture. Any other or extended use is considered improper. Intended use also includes compliance with all instructions in the user manual. Foreseeable misuse Improper use of the product may result in dangers to life and limb as well as property damage. For this reason, improper use is prohibited. -
Page 9: Product Description
Variant Type 10 EcoPack 740 mm Variant Type 16 740 mm For the Telescope variants, you can change these settings according to your needs. The corresponding descriptions are available under Operation and settings. FrameOne Plus Manual -en- 2017 Page 9 of 29... -
Page 10: Components
Product description Components The FrameOne Plus desk consists mainly of the following components (description of the variants are available under the respective chapter): Desktop with plastic parts for plate mounting Optional: sliding top Side panels Modesty panels ... -
Page 11: Overview Of Frameone Plus Desk
Product description Overview of FrameOne Plus desk Each illustration shows one of many design variants of the FrameOne Plus desk. The illustrations merely serve to demonstrate the desk components. Fig. 1 Type 10 Standard Fixed Top Fig. 2 Type 10 Standard Sliding Top, Variant Telescope... -
Page 12: Transport And Storage
If you want to store the desk temporarily before installation, the following conditions must be met: The transport packaging must be intact. Sufficient carrying capacity of the floor. Dry floor. Horizontal storage surface. Temperature range +5 °C to +40 °C. FrameOne Plus Manual -en- 2017 Page 12 of 29... -
Page 13: Installation And Assembly
Corner protectors made of polyethylene (PE). These materials are recyclable. When the product is assembled by Steelcase or an authorised installer, the packaging is disposed of by the manufacturer. If you install yourself, please ensure sorted separation and return to the recycling cycle. - Page 14 Installation and assembly Fig. 4 FrameOne Plus Standard height compensation Adjusting screw Procedure: Turn adjusting screw (1) until the height adjustment is complete. FrameOne Plus Manual -en- 2017 Page 14 of 29...
-
Page 15: Disassembling And Reassembling The Desk Temporarily
If you want to disassemble the desk for good and dispose of it, follow the instructions under Disposal of the desk. Reassembling the desk For reassembly, see Installation and assembly on Page 13 FrameOne Plus Manual -en- 2017 Page 15 of 29... -
Page 16: Operation And Settings
Operation and settings Operation and settings Safety instructions The desk FrameOne Plus may be used and operated only in perfect technical condition and in compliance with the user manual. Before you change the desk height, make sure of the following: ... -
Page 17: Carrying Out Height Compensation
Fig. 5 Type 10 Standard height compensation Fig. 6 Type 10 Loop height compensation Adjusting screw Adjusting screw Procedure: Remove all objects from the desk. Turn adjusting screw (1) until the height adjustment is complete. FrameOne Plus Manual -en- 2017 Page 17 of 29... -
Page 18: Height Adjustment
Operation and settings Height adjustment Height adjustment is only possible on variants Telescope. Height adjustment of the FrameOne Plus Type 10 Standard, Type 10 EcoPack and Type 16 desks is done in the same way. Type 10 Standard, variant Telescope was used for the illustration. -
Page 19: Sliding Top (Optional)
Operation and settings Sliding top (optional) The FrameOne Plus desk is available with a sliding desktop (not for depth 600). The sliding top allows you to reach the cable duct even if the rear of the desk is not accessible. -
Page 20: Closing The Sliding Desktop By User
Push the sliding desktop (1) in until it reaches the stop at the safety lock. Closing the desktop locking mechanism: pull handle (2), slide in sliding desktop (1) to the stop and allow the lock to engage, unload handle (2). FrameOne Plus Manual -en- 2017 Page 20 of 29... -
Page 21: Opening Sliding Desktop By Facility Manager
Opening desktop locking mechanism: open the movable part of the safety lock (1) sideways on both sides in the direction of the centre of the panel. Pull out the sliding desktop (2) up to the stop. FrameOne Plus Manual -en- 2017 Page 21 of 29... -
Page 22: Closing Sliding Desktop By Facility Manager
Keep hands and fingers away from moving parts. NOTICE Closed desktop locking mechanism may damage the sliding desktop when closing! To close the sliding desktop, the desktop locking mechanism must be open. (For procedure, see next page) FrameOne Plus Manual -en- 2017 Page 22 of 29... - Page 23 Push the sliding desktop (2) in until it reaches the stop at the safety lock (1). Opening desktop locking mechanism: turn in the movable part of the safety lock (1) sideways and engage using the safety lock. FrameOne Plus Manual -en- 2017 Page 23 of 29...
-
Page 24: Faults And Malfunctions
Faults and malfunctions Faults and malfunctions If malfunctions occur during operation, please check whether the FrameOne Plus desk has been handled according to the user manual. In most cases, this will help you find and eliminate the problem. If it is not possible to eliminate fault or malfunctions, please contact our Customer Service Department (see Repairs and spare parts on Page 29). -
Page 25: Maintenance
Only appropriately qualified and authorised personnel may carry out maintenance and repair work. Only use suitable tools for these operations! Functional checks The components of the FrameOne Plus desk should be checked for their functionality at regular intervals. Table for functional checks Interval... -
Page 26: Maintenance Work
Coordinate the installation of other parts with Steelcase. Observe the specified maintenance and inspection intervals. Disclaimer of liability Steelcase assumes no liability or warranty in the following cases (see Liability on Page 2). Inadequate monitoring of the product components (function checks). ... -
Page 27: Cleaning And Care
You can use commercial cleaning agents to clean the surfaces of the desk. NOTICE Material damage due to unsuitable care measures is possible! Only use care and cleaning agents that are suitable for the appropriate materials (plastic, metal). FrameOne Plus Manual -en- 2017 Page 27 of 29... -
Page 28: Disposal Of The Desk
Disposal of the desk Disposal of the desk Disassembly should be carried out by qualified personnel. Follow these steps to disassemble and dispose of the FrameOne Plus desk Disassemble the desk into its components. Separate the resulting parts into: ... -
Page 29: Customer Service
+34 914 759 000 241 Italy +39 (051) 65 00 708 The Netherlands Belgium Luxembourg Scandinavia +31 30 634 62 41 Baltic states Poznań Czech Republic Slovakia other +33 (0) 3 88 13 37 96 FrameOne Plus Manual -en- 2017 Page 29 of 29...
