1144 SERIES KEY FOB
TRANSMITTERS
Installation Guide
Figure 1: 1144-D Key Fob
DESCRIPTION
The 1144 Series Wireless
Key Fobs include the 1144‑1
One‑Button, 1144‑2 Two‑Button,
1144‑D Dual‑Button, and 1144‑4
Four‑Button transmitters.
Each key fob features a durable
water‑resistant housing designed to
be clipped to a key ring or lanyard,
ergonomic button design, and a
status LED that indicates system
status with color‑coded responses.
Variants include models with a
1306P Prox Patch™ credential,
128‑bit AES encryption, or panic
supervision mode. For more
information, refer to "Ordering
Information".
Compatibility
All DMP XT Series and XR Series
Panels and all 1100 Series Wireless
Receivers
To use wireless encryption, panels
must have firmware Version 183 or
higher and wireless receivers must
have firmware Version 300 or higher.
What is Included?
One Key Fob Transmitter with
extra serial number label
One 1306P Prox Patch credential
(1144‑1P and 1144‑2P only)
One Sony® CR2430 3.0 V Lithium
Coin Battery
Peel‑off Button Labels (not
included with 1144‑D)
OPERATION
Each button on the 1144‑1, 1144‑2, and 1144‑4 can be individually
programmed for one of nine different actions. The 1144‑D provides two
buttons that, when pressed at the same time, send a panic message to the
control panel for annunciation.
Figure 2 shows the key fob button configurations. Table 1 shows the default
programming for each button.
1144-1 and 1144E-1
1-Button Layout
One (Top)
Button
Front View
Top
Button
Left
Button
Bottom
Button
Figure 2: 1100 Series Key Fob Transmitters
KEY FOB MODEL
1144‑1 One‑Button
1144‑2 Two‑Button
1144‑D Panic
Dual‑Button
1144‑4 Four‑Button
Table 1: Default Key Fob Programming
1144-2 and 1144E-2
2-Button Layout
Top
Button
Bottom
Button
1144-4 and 1144E-4 4-Button Layout
Side View
LED
Front
Right
Button
Connect Key Ring or
Lanyard Here
BUTTON POSITION
DEFAULT PROGRAMMING
Top
Panic
Top
Arm
Bottom
Disarm
Top and Bottom
Panic 2
together
Top
Arm
Bottom
Disarm
Left
Panic
Right
Arm Area 1 or Perimeter
1144-D Panic
2-Button Layout
Top
Button
Bottom
Button
Side View
with Prox Patch
Back
Back
Front
