Summary of Contents for DMP Electronics 1103 Series
- Page 1 INSTALLATION GUIDE 1103 Series Wireless Universal Transmitter...
-
Page 2: Get Started
Both sets of contacts can be programmed to operate at the same time. This allows two independent zones to operate from one 1103. The 1103 Series also features Disarm/Disable functionality. When this option is enabled, Zone Tripped messages are disabled when the system is disarmed. -
Page 3: Installation
Energizer® 123 battery or a CR123A battery manufactured by Panasonic or Tekcell. Push the button on the end of the transmitter and separate the two halves. Observing polarity, place the battery in the holder and press it into place. Refer to Figure 1 during installation. 1103 Series Installation Guide | Digital Monitoring Products... -
Page 4: Mount The Transmitter
Use the LED Survey to Select a Location The 1103 Series Wireless Univeral Transmitter provides a Survey LED capability to allow one person to confirm communication with the wireless receiver or panel while the cover is removed. With the cover removed, hold the transmitter in the exact desired location. - Page 5 Tech APP™ to perform a Wireless Check-in Test on the system or complete the following steps to perform a Check-in Test from a keypad that is connected to the panel. At the keypad, enter 8144 (WALK) and select WLS. 1103 Series Installation Guide | Digital Monitoring Products...
-
Page 6: Additional Information
In addition, the supplied magnet must be mounted next to the 1103 internal contact to restore the zone and allow the tamper switch to have priority. This issue does not exist when the transmitter is installed with the XR150/XR550 Series panels. 1103 Series Installation Guide | Digital Monitoring Products... -
Page 7: Specifications
ANSI/UL 1023 Household Burglar Alarm System Units ANSI/UL 1076 Proprietary Burglar Alarm Units ANSI/UL 1610 Central Station Burglar Alarm Units ANSI/UL 864 Fire Protective Signaling Systems Patents ▶ U. S. Patent No. 7,239,236 1103 Series Installation Guide | Digital Monitoring Products... -
Page 8: Fcc Information
FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made by the user and not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
