System Overview

C8051F330/1/2/3/4/5 devices are fully integrated mixed-signal System-on-a-Chip MCUs. Highlighted fea-
tures are listed below. Refer to Table 1.1 for specific product feature selection.
High-speed pipelined 8051-compatible microcontroller core (up to 25 MIPS)
In-system, full-speed, non-intrusive debug interface (on-chip)
True 10-bit 200 ksps 16-channel single-ended/differential ADC with analog multiplexer
10-bit Current Output DAC
Precision programmable 25 MHz internal oscillator
Up to 8 kB of on-chip Flash memory—512 bytes are reserved
768 bytes of on-chip RAM
SMBus/I2C, Enhanced UART, and Enhanced SPI serial interfaces implemented in hardware
Four general-purpose 16-bit timers
Programmable Counter/Timer Array (PCA) with three capture/compare modules and Watchdog Timer
function
On-chip Power-On Reset, V
On-chip Voltage Comparator
17 Port I/O (5 V tolerant)
With
on-chip
Power-On
C8051F330/1/2/3/4/5 devices are truly stand-alone System-on-a-Chip solutions. The Flash memory can
be reprogrammed even in-circuit, providing non-volatile data storage, and also allowing field upgrades of
the 8051 firmware. User software has complete control of all peripherals, and may individually shut down
any or all peripherals for power savings.
The on-chip Silicon Labs 2-Wire (C2) Development Interface allows non-intrusive (uses no on-chip
resources), full speed, in-circuit debugging using the production MCU installed in the final application. This
debug logic supports inspection and modification of memory and registers, setting breakpoints, single
stepping, run and halt commands. All analog and digital peripherals are fully functional while debugging
using C2. The two C2 interface pins can be shared with user functions, allowing in-system debugging with-
out occupying package pins.
Each device is specified for 2.7 to 3.6 V operation over the industrial temperature range (–40 to +85 °C).
The Port I/O and RST pins are tolerant of input signals up to 5 V. The C8051F330/1/2/3/4/5 are available in
20-pin QFN packages (also referred to as MLP or MLF packages). Lead-free (RoHS compliant) packages
are also available. See Table 1.1 for ordering part numbers. Block diagrams are included in Figure 1.1,
Figure 1.2, Figure 1.3, Figure 1.4, Figure 1.5, and Figure 1.6.
Monitor, and Temperature Sensor
DD
Reset,
V
monitor,
DD
