Fill in "Start time" and "Percentage"(PF), and click "Save".
- - - - E E n n d d
S S u u b b s s e e q q u u e e n n t t O O p p e e r r a a t t i i o o n n
Delete local power control manner: select a local power control manner that needs to be
deleted, and click "Clear data".
10.2.2.4 AI Control
When using the analog signal at the AI port of the Logger3000 as the dispatching input,
set the reactive control mode to "Analog input".
step 1 Click "Power control" -> "Reactive power" to enter the reactive power interface.
step 2 Set the reactive control mode to "Analog input".
step 3 Set AI control parameters. For specific parameter description, refer to the following
table.
P P a a r r a a m m e e t t e e r r
Communication
abnormality output
(%)
Control method
Select energy
meter*
Control cycle
AI port
Q-Method
Min. / Max.
D D e e s s c c r r i i p p t t i i o o n n
Communication is abnormal, and specified dispatch output
value is delivered.
Open loop control: Reactive instruction controlled by AI is sent
to power output port of the inverter, thereby achieving active
power control.
Closed-loop control: Reactive instruction controlled by AI is
used as target value and reactive power and power factor of
the meter need to be collected and used as input parameters,
and reactive power compensation ratio is calculated and sent
to power output port of the inverter. Generally, this strategy is
used for improving the power factor of the property boundary
point.
Select Smart Energy Meter involved in power regulation
Time interval of delivering dispatching instructions
Parameter range: 5~60s
AI1~AI4 available
PF: set the power factor as the target value
%: set reactive power percentage
When "Q-Method" is set to "%", the parameter ranges from
-100.0% to 100.0%.
When "Q-Method" is set to "PF", the parameter ranges from
-1 to -0.8 or 0.8 to 1.
