9.3 Web Main Interface

When the "O&M user" logs into the Web for the first time, the "Help" window pops up.
Follow the prompts to perform operations such as time synchronization, device
connection, and forwarding configuration.
The Web main interface is as follows:
I I t t e e m m
A
B
C
D
E
F
G

9.4 Web Menu

The Web has seven main function modules: "Overview", "Device monitoring", "Device",
"Power Control", "History Data", "System", and "About".
D D e e s s i i g g n n a a t t i i o o n n
Navigation menu
Function display area
Alarm icon
Help
Language menu
User
Information icon
D D e e s s c c r r i i p p t t i i o o n n
Display main function modules of the
Web
Display the current interface
Display the current alarm level and alarm
number. Users can click the icons to
enter the corresponding alarm interface
Display the basic configuration steps of
the Logger3000
Click the button to select the desired
language
Display the current login user
: Connection state of ETH1 port
: Connection state of ETH2 port
: Cloud service
