2.3 Address Setup Rotary Switch

The two rotary switches SW1 and SW2 set up the node address on
DeviceNet in decimal form. Setup range: 00 ~ 63 (64 ~ 99 are forbidden).
1. Example:
If you need to set the node address of IFD9502 as 26, simply switch the corresponding rotary switch of X10
to "2" and the corresponding rotary switch of X10
Address setting
0 ~ 63
64 ~ 99
2. Note:
The changed values on SW1 or SW2 are only valid when IFD9502 is re-powered. When IFD9502 is operating,
changing the set value of node address will be invalid.

2.4 Function Setup DIP Switch

The DIP switch SW3 is to be used on the equipment connected to
IFD9502, the selection of communication ports and setting up the baud
rate of IFD9502 and the master in DeviceNet.
1. Selecting equipment connected to IFD9502
PIN 3
Off
Off
Off
On
On
On
On
Example
If the equipment connected to IFD9502 is Delta servo drive, you only need to switch PIN 3 in SW3 to
"On" and PIN 1 and PIN 2 to "Off" and re-power IFD9502.
Note:
The changed setting of DIP switch is only valid when IFD9502 is re-powered. When IFD9502 is
operating, changing the setting of DIP switch will be invalid.
2. Selecting IFD9502 communication mode
PIN 5
Off
On
Off
On
DVP-PLC Application Manual
DeviceNet Slave Communication Module IFD9502
Valid DeviceNet node address
Invalid DeviceNet node address
PIN 2 PIN 1
Off On
On Off
On On
Off Off
Off On
On Off
On On
PIN 4
Off
On
On
Off
0
to "6".
Description
Equipment
AC motor drive
Programmable logic controller
Temperature controller
Servo drive
Human machine interface
Custom equipment
Configuration mode
Communication mode
RS-485
RS-232
Incorrect setting
1
SW3
ON DIP
1 2 3 4 5 6 7 8
5
