  • Page 1 DVPPF02-SL PROFIBUS DP Slave Communication Module Operation Manual DVP-0155320-02...

  • Page 3: Table Of Contents

    2.2 Specifications ....................4 Installation......................5 Dimensions ....................5 Connecting DVPPF02-SL to PLC ..............5 Installing DVPPF02-SL and PLC on DIN Rail ............ 5 PIN Definition for PROFIBUS DP Port .............. 6 Connecting to PROFIBUS DP Port ..............6 Address Switch ................... 6 Establishing PROFIBUS DP Network by DVPPF02-SL .........
  • Page 4 PROFIBUS DP Slave Communication Module DVPPF02-SL 10.1 Configuration of the master ................13 10.2 I/O mapping relationship between master PLC and slave PLC ......32 10.3 Write PLC programs ..................35 DVP-PLC Operation Manual...

  • Page 5: Introduction To Dvppf02-Sl

    PROFIBUS DP protocol, please refer to relevant references or literatures. 3. DVPPF02-SL is a PROFIBUS DP slave communication module, used for connecting the Delta series PLC such as DVP-SV, DVP-SX2, DVP-SV3 and DVP-SX3 to the PROFIBUS DP network. DVPPF02-SL works as a left-side extension module of the DVP PLC, and no external power supply is required when it is used since its power is supplied by the PLC.

  • Page 6: Specifications

    PROFIBUS DP Slave Communication Module DVPPF02-SL 2.2 Specifications PROFIBUS DP Port Interface DB9 connector Transmission method High-speed RS-485 Transmission cable Shielded twisted pair cable Electrical isolation 500 VDC Communication Data type Cyclic data exchange Module name DVPPF02-SL GSD document DELA0AFE.GSD...

  • Page 7: Installation

    Use 35mm DIN rail.  Open the DIN rail clips on DVPPF02-SL and the PLC and then insert DVPPF02-SL and the PLC onto the DIN rail.  Clip up the DIN rail clip on DVPPF02-SL and the PLC to fix them on the DIN rail.

  • Page 8: Pin Definition For Profibus Dp Port

    DVPF02-SL and the PROFIBUS DP bus are properly connected. 3.6 Address Switch The address switches on DVPPF02-SL are used for setting up the node address of DVPPF02-SL on the PROFIBUS DP network. The switches are two rotary switches x16 and x16 .

  • Page 9: Establishing Profibus Dp Network By Dvppf02-Sl

    A. 26 (decimal) = 1A (hex) = 1×16 + A×16 Notes: Set up the address of DVPPF02-SL when the power is off. Re-power the module after you finish setting  up the address. Changing the setting of address when DVPPF02-SL is operating is regarded invalid.

  • Page 10: Gsd File

    I/O. When using DVPPF02-SL, first import the GSD file to the software for configuring the PROFIBUS DP master, then DVPPF02-SL and items to be configured will be displayed in the software. You can download the GSD file for DVPPF02-SL from Delta official website: http://www.deltaww.com.

  • Page 11: Configuring Dvppf02-Sl

    Configuring DVPPF02-SL 8.1 Configuring DVPPF02-SL When you configure DVPPF02-SL in the software for PROFIBUS DP master and DVPPF02-SL is offline from the PROFIBUS DP master, you can select to “clear I/O data” or “hold I/O data”, as shown below. Figure 8.1-1...

  • Page 12: I/O Configuration For Dvppf02-Sl

    PROFIBUS DP Slave Communication Module DVPPF02-SL 8.2 I/O Configuration for DVPPF02-SL When DVPPF02-SL is configured in the software for the PROFIBUS DP master, it offers many choices for configuration, satisfying all kinds of data length demands. See the table below. The output configuration means the data is sent from the master to the salve;...
  • Page 13 2. When DVPPF02-SL is in normal operation status and the PLC is in STOP status, the digital display will how its node address and the STOP status code alternately. 3. When DVPPF02-SL is initializing or in error status and the PLC is in RUN status, the digital display will show its node address, initialization code or error code alternately.

  • Page 14: Application Example

    Connecting DVPPF02-SL to the PROFIBUS DP Network:  1. AH10PFBM-5A is the PROFIBUS DP master and DVPPF02-SL is the slave. See Figure 10-1 for the network structure. Figure 10-1 2. Set the PROFIBUS station address of DVPPF02-SL to “2”.
  • Page 15 PROFIBUS DP Slave Communication Module DVPPF02-SL 10.1 Configuration of the master 1. Open the master configuration software SYCON.net, and the "SYCON.net User Login" dialog box will show up, as shown in the following figure: Select Administrator for "User Name". Fill nothing in "Password", which is the default password setting. For detailed settings, please refer to section 7.1 in the SYCON.net software help.
  • Page 16 PROFIBUS DP Slave Communication Module DVPPF02-SL Find the master module on the right-side interface, and then select and drag it to the position shown in the following figure. When a "+" sign appears next to the mouse, release the mouse to add the master module.
  • Page 17 PROFIBUS DP Slave Communication Module DVPPF02-SL Double-click on the master to enter the master parameter setting window and set up the master communication parameters. (Note: Before you set up communication parameters, the computer needs to be connected to the master's "CONF"...
  • Page 18 PROFIBUS DP Slave Communication Module DVPPF02-SL 7. Click on "Device Allocation" in the left-side window, and then click "Scan" button in the right-side window. After scanning is over, select the "All" option for "Device selection" After the master is scanned out, check the box of the master scanned out.
  • Page 19 PROFIBUS DP Slave Communication Module DVPPF02-SL 9. After finishing setting the master parameters, click the "OK" button to exit the master configuration window and return to the main interface. 10. Select and right-click the master, and then the context menu appears, from which you select the "Network Scan…"...
  • Page 20 PROFIBUS DP Slave Communication Module DVPPF02-SL 11. Scan out the slave connected to the master. 12. Select the DTM device DVPPF02-SL that is consistent with the actual slave. DVP-PLC Operation Manual...
  • Page 21 PROFIBUS DP Slave Communication Module DVPPF02-SL 13. Click "Create Devices" button in the figure above to add the slave device. 14. Select and right-click the master, and then the context menu appears, from which you select "Disconnect" option. DVP-PLC Operation Manual...
  • Page 22 DVPPF02-SL, while “Configured Modules” shows actually configured modules. The “Length of input/output data” of DVPPF02-SL is the sum of the input and output lengths of all configured modules. The data lengths for Inputs, Outputs and In/Out marked in the red box are denoted in bytes. “Length of input data” and “Length of output data”...
  • Page 23 PROFIBUS DP Slave Communication Module DVPPF02-SL Insert: When there are no modules in the "Configured Modules" section, select the module you want in the "Available Modules" section and click the "Insert" button to add the selected module to the "Configured Modules".
  • Page 24 PROFIBUS DP Slave Communication Module DVPPF02-SL 17. Click "Parameters" in the left-side window and then click the place of Common in the red box in the following figure. DVP-PLC Operation Manual...
  • Page 25 A dropdown menu appears, by which you can set up the parameters of each I/O module for the slave.  When selecting Common, the parameter setting of the DVPPF02-SL module will be presented. To modify the parameter, double-click the parameter setting in the "Value" column. If the mouse symbol changes to the "I"...
  • Page 26 PROFIBUS DP Slave Communication Module DVPPF02-SL Click "Extensions" for the setup in the following figure: Note: The settings here are default ones. For details, see section 10.2 in the SYCON.net help. DVP-PLC Operation Manual...
  • Page 27 PROFIBUS DP Slave Communication Module DVPPF02-SL 19. After the configuration of modules for the slave is done, click the "OK" button to exit the configuration window, and return to the main interface. 20. Double-click on the master icon to enter the window for master parameters setting, where you can set up the master parameters.
  • Page 28 PROFIBUS DP Slave Communication Module DVPPF02-SL 21. Click on "Bus Parameters" to set the bus parameters. 22. Check the box of "Overwrite slave specific Watchdog Control Time" and click "Adjust" to automatically adjust the bus parameters. Note: For details, please refer to section 10.3.2 in the SYCON.net help.
  • Page 29 PROFIBUS DP Slave Communication Module DVPPF02-SL 23. Click "Address Table" in the left window to set the mapping addresses for the master PLC. For details, please refer to section 10.2 for the I/O mapping relationship between the master PLC and the slave PLC.
  • Page 30 PROFIBUS DP Slave Communication Module DVPPF02-SL 24. Click on "Station Table", and check the box in Activate column in the following figure to change the node address of the slave in the configuration. Note: Please make sure to check the box in Activate column. If not, the configuration of the slave will be ineffective.
  • Page 31 PROFIBUS DP Slave Communication Module DVPPF02-SL 26. After completing the master parameter settings, click the "OK" button to exit the master parameter settings window and return to the main interface. DVP-PLC Operation Manual...
  • Page 32 PROFIBUS DP Slave Communication Module DVPPF02-SL 27. Select and right-click the master module, and then a context menu shows up, from which you select "Download" to download the configuration data to the master. 28. After the following dialogue box pops up, click the "Yes" button to continue downloading.
  • Page 33 PROFIBUS DP Slave Communication Module DVPPF02-SL 29. After downloading is over, return to the main interface. Note: After the download is completed, all three indicator lights on the master turn green and the digital display shows the station address of the master, which indicates that the network communication is normal.
  • Page 34 PROFIBUS DP Slave Communication Module DVPPF02-SL 10.2 I/O mapping relationship between master PLC and slave PLC The input and output areas allocated by the AH master PLC to the master module are shown in the following figure. (For details, see section 15.1 in the SYCON.net help.) The following figure shows the starting addresses and lengths for the OUTPUT and INPUT areas allocated by the master PLC to the master module in this example.
  • Page 35 INPUT area + (Address offset / 2). Please pay your attention to the descriptions mentioned above when the master and the DVPPF02-SL slave are connected. The mapping relationship between the master PLC’s D registers and the slave’s configuration modules is related to the master parameters setting.
  • Page 36 In the two example figures above, the AH master’s PLC respectively assigns D1000 and D3000 as the starting addresses of the INPUT and OUTPUT areas to the master module. The mappings between the master PLC’s registers and the slave DVPPF02-SL’s configuration modules are shown in the following table.
  • Page 37 Write the PLC program for the master in the ISPSoft software. When the master PLC is running and M0 is ON, the master PLC starts to control DVPPF02-SL’s configuration modules. When M1 is ON, the master PLC reads corresponding values of DVPPF02-SL’s configuration modules.
  • Page 38 Delta PLC programs can be written in the WPLSoft software. For details on programming, refer to the  WPLSoft help. When M0 is ON, write 3000 to D6250 and 4000 to D6251. DVPPF02-SL transmits the data in D6250 and  D6251 to the D1000 and D1001 in the master through the PROFIBUS DP bus.
