DeviceNet Slave Communication Module IFD9502
18
Attribute ID Access rule
1 Get/Set
2 Get/Set
3 Get/Set
11 Get/Set
12 Get/Set
13 Get/Set
14 Get/Set
15 Get/Set
16 Get/Set
17 Get/Set
18 Get/Set
19 Get/Set
20 Get/Set
21 Get/Set
22 Get/Set
23 Get/Set
24 Get/Set
25 Get/Set
26 Get/Set
31 Get/Set
32 Get/Set
33 Get/Set
34 Get/Set
35 Get/Set
36 Get/Set
37 Get/Set
38 Get/Set
39 Get/Set
40 Get/Set
41 Get/Set
42 Get/Set
43 Get/Set
44 Get/Set
45 Get/Set
46 Get/Set
Data_in refers to data transmitted from DeviceNet master to servo drive. Data_out
refers to data transmitted from the servo drive to DeviceNet master.
Name Data type
Reset parameter USINT
Input data length USINT
Output data length USINT
Data_in [0] UINT
Data_in [1] UINT
Data_in [2] UINT
Data_in [3] UINT
Data_in [4] UINT
Data_in [5] UINT
Data_in [6] UINT
Data_in [7] UINT
Data_in [8] UINT
Data_in [9] UINT
Data_in [10] UINT
Data_in [11] UINT
Data_in [12] UINT
Data_in [13] UINT
Data_in [14] UINT
Data_in [15] UINT
Data_out [0] UINT
Data_out [1] UINT
Data_out [2] UINT
Data_out [3] UINT
Data_out [4] UINT
Data_out [5] UINT
Data_out [6] UINT
Data_out [7] UINT
Data_out [8] UINT
Data_out [9] UINT
Data_out [10] UINT
Data_out [11] UINT
Data_out [12] UINT
Data_out [13] UINT
Data_out [14] UINT
Data_out [15] UINT
Default
H'0000
1 words
1 words
H'0407
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'0409
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
H'FFFF
