Delta Electronics DeviceNet IFD9502 Applications Manual page 25

Byte position
Format of messages responded:
Byte position
3. Class 0x9E Custom_Parameter
Class attributes
Instance 1: Parameter Instance 1 through N
Parameter attribute
Common Services
Service Code
0x0E
0x10
Explanation
4. I/O data mapping (Default)
Custom equipment → DeviceNet master
Node address of custom
DVP-PLC Application Manual
DeviceNet Slave Communication Module IFD9502
Data written into custom equipment
5
6 Service Data LSB
7 Service Data MSB
Data written into custom equipment
0 Frag [0]+XID+MAC ID
1 R/R [1]+Service code [0x10]
2
3
Attribute ID Access rule
1
Attribute ID Access rule
1
Implemented for
Class Instance
Yes
No
When you need to use DeviceNet Config software to read the parameters in the custom
equipment, you have to first make sure that the equipment supports the Modbus function
code, 0x03 (read), 0x06 (write) and so on.
You have to acquire the Modbus address of the parameter before reading the parameter.
How to read: Plus 0x0001 in Modbus address as Instance value and 0x0001 as Attribute
value.
Assume you read the Modbus address of the custom equipment as 0x011E, use DeviceNet
Config software and read Instance = 0x011E + 0x0001 and Attribute = 0x01.
b15 b14 b13 b12 b11 b10 b9
equipment
H'2101
H'2102
Attribute ID
N/A
N/A
Get Revision
Get/Set Parameter Value
Yes Get_Attribute_Single
Yes Set_Attribute_Single
Relevant to the equipment connected
Relevant to the equipment connected
Data read from custom equipment
Attribute ID
N/A
N/A
Data read from custom equipment
Frag [0]+XID+MAC ID
R/R [1]+Service code [0x0E]
Response data LSB
Response data MSB
Name Data type
UINT
Name Data type
Service Name
b8 b7 b6 b5 b4
-
b3 b2 b1 b0
23
