DeviceNet Slave Communication Module IFD9502
DeviceNet master → custom equipment
Node address of custom
Explanation
24
b15 b14 b13 b12 b11 b10 b9
equipment
H'2000
H'2001
When the equipment connected to IFD9502 is custom equipment, the length of data
downloaded from IFD9502 to the equipment is preset as 2 words at addresses H'2101 and
H'2102. IFD9502 is able to download maximum 4 words. The length of data uploaded to
IFD9502 from the equipment is preset as 2 words at addresses H'2000 and H'2001.
IFD9502 is able to be uploaded maximum 4 words. The I/O mapping can be modified by
changing Class9F.
The length of I/O data to be exchanged and address for mapping can be modified through
changing Class9F as listed below. The modification will be valid after IFD9502 is
re-powered. Maximum 8 words are allowed for I/O data exchange.
If you are to return the I/O mapping to default setting, change Attribute1 of Instance1 of
Class 0x9F into H'0001 and re-power IFD9502. Please note that doing so can only recover
the current I/O data mapping in the custom equipment.
Class 0x9F Custom Data Config
Instance0:
Attribute ID Access rule
1 Get
Instance1:
Attribute ID Access rule
1 Get/Set
2 Get/Set
3 Get/Set
9 Get/Set
10 Get/Set
11 Get/Set
12 Get/Set
17 Get/Set
18 Get/Set
19 Get/Set
20 Get/Set
If IFD9502 fails to connect to DeviceNet by explicit messages due to the modification
on the I/O mapping between IFD9502 and the equipment connected to it (e.g. dlen_in,
dlen_out, data_in, data_out, etc), the I/O mapping between IFD9502 and the equipment
connected to it will not be able to return to default setting through explicit messages.
In the custom mode, DNAIFD9502 can still establish EXP/IO connection when there is no
equipment connected to it and the I/O mapping of IFD9502 can be returned to default
b8 b7
Relevant to the equipment connected
Relevant to the equipment connected
Name
Revision
Name Data type
Reset parameter USINT
Input data length USINT
Output data length USINT
Data_in [0]
Data_in [1]
Data_in [2]
Data_in [3]
Data_out [0]
Data_out [1]
Data_out [2]
Data_out [3]
b6 b5 b4 b3 b2 b1
Data type
UINT
Default
H'0000
2 words
2 words
UINT H'2000
UINT H'2001
UINT H'FFFF
UINT H'FFFF
UINT H'2101
UINT H'2102
UINT H'FFFF
UINT H'FFFF
DVP-PLC Application Manual
b0
