DVP-PLC Application Manual
DeviceNet Slave Communication Module IFD9502
setting.
Instance2 EEPROM read/write:
Attribute ID (decimal) Access rule
30
71
90
150
224
200
In the custom mode, if you are to return the I/O mapping of AC motor drive to default
setting, change Attribute30 of Instance2 of Class 0x9F into H'0001 and re-power IFD9502.
In the custom mode, if you are to return the I/O mapping of PLC to default setting,
change Attribute71 of Instance2 of Class 0x9F into H'0001 and re-power IFD9502.
In the custom mode, if you are to return the I/O mapping of temperature controller to
default setting, change Attribute90 of Instance2 of Class 0x9F into H'0001 and re-power
IFD9502.
In the custom mode, if you are to return the I/O mapping of servo drive to default
setting, change Attribute150 of Instance2 of Class 0x9F into H'0001 and re-power IFD9502.
In the custom mode, if you are to return the I/O mapping of HMI to default setting,
change Attribute224of Instance2 of Class 0x9F into H'0001 and re-power IFD9502.
In the custom mode, if you are to return the I/O mapping of the custom equipment to
default setting, change Attribute200 of Instance2 of Class 0x9F into H'0001 and re-power
IFD9502.
Common Services:
Service Code
Class
005 Yes
0x0E Yes
0x10 No
Instance3 Modbus baud rate setting
Attribute ID
Access rule
(decimal)
1 Get/Set
2 Get/Set
3 Get/Set
4 Get/Set
5 Get/Set
6 Get/Set
Note 1: The baud rates of the codes are in the table below.
Get/Set AMD reset parameter
Get/Set PLC reset parameter
Get/Set DTA reset parameter
Get/Set ASDA reset parameter
Get/Set DOP reset parameter
Get/Set Custom reset parameter
Implemented for
Instance
Yes
Yes
Yes
Name
AMD baud rate setting
PLC baud rate setting
DT baud rate setting
ASDA baud rate setting
DOP baud rate setting
CUSTOM baud rate setting
Name
Service name
Reset
Get_Attribute_Single
Set_Attribute_Single
Range Default value
(Note 1) (Note 1)
1 ~ 2
1 ~ 4
1 ~ 2
1 ~ 4
1 ~ 4
1 ~ 4
Default
H'0000
H'0000
H'0000
H'0000
H'0000
H'0000
2
4
2
4
4
1
